Inserting The Battery - LaserLiner CableTracer Pro Mode D'emploi

F G H I
Q P O
2

Inserting the battery

Ensure correct polarity! The battery symbol in the receiver's and sender's LC display indicates, when the
batteries need to be exchanged.
1.
LC display receiver RECV
F Display bars (full bars = maximum strength):
Signal strength (SIG) / Strength of electromagnetic field
(NCV)
J
G Mains voltage mode (NCV)
K
H Battery charge status indicator
L
I Automatic search mode ON (SIG)
J Display for flashlight ON
M
K Manual search mode:
N
Display of level of sensitivity selected
L Automatic search mode: numeric display of signal strength-
Manual search mode: numeric display of signal strength,
value depends on sensitivity selected
M Display for acoustic signal OFF
N Display of output power of transmission signal selected by
Sender TX , level I, II, III.
O Display of sender code received (1,2,3,4,5,6,7)
P Manual search mode ON
Q External voltage warning
2.
6LR61 9V
Alkali
CableTracer Pro
1.
6LR61 9V
Alkali
2.
19
GB
