Quick start guide
Air Cooler
For more information see the extended manual
online: ned.is/COOL115CWTP
Intended use
The Nedis COOL115CWTP is an air cooler with a 3 L water tank
capacity.
The product is exclusively intended as an air cooler.
The product is intended for indoor use only.
The product is not intended for professional use.
Any modification of the product may have consequences for safety,
warranty and proper functioning.
Main parts (image A)
1
Cover
2
Ice pack
3
Water tank
4
Air filter
5
Curtain paper
6
Air filter slot
7
Air cooler
8
Water tank lock
9
Water tank slot
10
Water hose
11
Power cable
12
Vertical air flow control
13
Air outlet
14
Remote
Safety instructions
-
WARNING
•
Only use the product as described in this manual.
•
Do not use a damaged product.
•
Disconnect the product from the power outlet and other
equipment if problems occur.
•
Do not drop the product and avoid bumping.
•
This product may only be serviced by a qualified technician for
maintenance to reduce the risk of electric shock.
•
Close supervision is necessary when the product is used by or
near children, animals or infirm persons. Do not allow children to
play with it or touch it.
•
Do not use the product in rooms where flammable liquids or
gases are used or stored.
•
Do not use the product in wet or damp environments.
•
Avoid direct sunlight.
•
Do not cover the product.
•
Do not use the product without water in the tank.
•
Do not use solvents to clean the product.
•
Only plug the cable into a wall outlet. Do not use extension
cords.
•
Only use a power outlet rated 10 A or higher.
•
Do not insert any objects into the product.
Setup
1. Place the product on a stable and flat surface.
w
2. Plug the power cable A
Filling the water tank
3
1. Fill A
with water.
-
Do not fill the water tank above the "max" indicator.
-
Do not use the product if the water level is below the "min"
indicator.
COOL115CWTP
15
Air flow on / off
16
Wind
17
Fan speed
18
Swing on / off
19
Cooler on / off
20
Timer
21
Cooler on / off
22
Swing on / off
23
Timer
24
Display
25
Wind
26
Fan speed
27
Air flow on / off
into the power outlet.
Using ice packs
4
The use of ice packs A
2
4
Use A
if water does not provide enough cooling.
Using the fan
k
1. Press A
to switch on the fan.
j
2. Press A
to set the fan speed.
g
A
indicates the current fan speed.
k
3. Press A
to switch off the fan.
Using the cooling function
s
•
Press A
to activate or deactivate the cooling function.
Setting air flow direction
d
1. Press A
to automatically swing the air flow from left to right.
e
2. Use A
to set the vertical air flow direction.
Setting the wind type
h
•
Press A
to set the wind type.
g
A
indicates the current wind type
Using the timer
f
•
Press A
to set the time to stand-by.
You can set the time to standby in 0.5 hr intervals from 0.5 – 7.5 hr.
A
g
indicates the time left to stand-by.
Specifications
Product
Article number
Dimensions (l x w x h)
Weight
Power input
Rated power
Water tank capacity
Air volume
Automatic air swing
Timer
Remote control
c
Kurzanleitung
Luftkühler
Weitere Informationen finden Sie in
der erweiterten Anleitung online:
ned.is/COOL115CWTP
Bestimmungsgemäße Verwendung
Der Nedis COOL115CWTP ist ein Luftkühler mit einem Wassertank
mit 3 l Kapazität.
Das Produkt ist allein zur Verwendung als Luftkühler gedacht.
Das Produkt ist nur zur Verwendung innerhalb von Gebäuden
gedacht.
Das Produkt ist nicht für den professionellen Einsatz gedacht.
Jegliche Modifikation des Produkts kann Folgen für die Sicherheit,
Garantie und ordnungsgemäße Funktionalität haben.
Hauptbestandteile (Abbildung A)
1
Abdeckung
2
Eispack
3
Wassertank
4
2
is optional.
Air Cooler
COOL115CWTP
280 x 250 x 560 mm
4.2 kg
220 – 240 VAC 50 – 60 Hz
80 W
3 L
270 m
/h
3
Yes
0.5 h – 7.5 h shut-off
Yes
COOL115CWTP
4
Luftfilter
5
Vorhangpapier
6
Luftfiltereinschub
