xINR18/65-y: Cylindrical lithium
Ion battery cells with max diameter
of 18mm and max height of 65mm;
"x" represents a number cells serial
connected, blank if 1; "-y" represents
a number of cells paralleled
connected, blank if 1
High speed
Low speed
Lock
Waste electrical products must not
be disposed of with household
waste. Please recycle where
facilities exist. Check with your local
authorities or retailer for recycling
advice.
OPERATING INSTRUCTIONS
NOTE: Before using the tool, read the
instruction book carefully.
INTENDED USE:
This tool is intended for the fastening and loosening
of bolts, nuts and various threaded fasteners. This
tool is not intended for use as a drill.
ASSEMBLY AND
OPERATION
ACTION
BEFORE OPERATION
Removing the Battery Pack
Charging the Battery
Installing the Battery Pack
Checking the battery condition (only for WX279)
ASSEMBLY
Inserting and Removing Socket (not
supplied)
Lithium-Ion Brushless impact wrench EN
Assembling the belt hook
OPERATION
Switch Lock
Forward And Reverse Rotation
Control
WARNING: Never Change
The Direction Of Rotation
When The Chuck Is Rotating,
Wait Until It Has Stopped!
Variable Speed Control
Operating the On/Off Switch
WARNING: Do not operate
for long periods at low
speed because excess heat will
be produced internally.
Using The LED Light
Before operation, the LED light
will be activated when the On/Off
switch is slightly depressed, and will
automatically turn off 20 seconds
after the On/Off switch is released.
The tool and battery are equipped
with a protection system. When
the LED Light is quickly flashing 3
seconds and turn off, the system
will automatically cut off power to
the tool to extend battery life. The
tool will automatically stop during
operation if the tool and/or battery
are placed under one of the following
conditions:
• Overloaded: The tool is operated
in a manner that causes it to draw
an abnormally high current. In this
situation, release the Trigger Switch
on the tool and stop the application
that caused the tool to become
overloaded. Then pull the Trigger
Switch again to restart.
• Overheated: Under the condition
above, if the tool does not start, the
Tool and Battery are overheated. In
FIGURE
this situation, let the Tool and Battery
cool before pulling the Trigger Switch
again.
• Low battery voltage: The
See Fig. A1
remaining Battery capacity is too low
See Fig. A2
and the tool will not operate. In this
situation, remove and recharge the
See Fig. A3
Battery.
WARNING:
See Fig. A4
To turn on the light, press the
On/Off switch and make sure the
Forward/Reverse Rotation Control is
on right/left position.
See Fig.
B1, B2
See Fig.
C1, C2
See Fig. D1
See Fig.
D2, D3
See Fig. E
See Fig. F
9
See Fig. F
