Proper use

The device is designed for making screw connec-
tions in the lower shell of trapezoidal roofs using the
original Würth system accessories.
Any other use than that described shall be deemed
to be improper use.
The user is liable for damage due to
improper use.

Device elements

Overview (fig. I / II)
1 Handle
2 Screwdriver
3 Lance
4 Attachment
5 ¼" Bit (size 25, length 120 mm)
6 Drive spindle
7 Adjustment ring
8 Guide rail
9 Strip guide
10 Belt strip
11 Screw length setting

Technical data

Screwdriving attach-
ment VSG 48 DB
Weight
Number of screws per belt
Screw length
8
Art. 0702 048 100
1.7 kg
50
4.8 x 20

Accessories and spare parts

In the unlikely event of a failure or defect, have the
device examined and repaired by a Würth master
Service workshop.
In all your queries and spare part orders, always
quote the product number (see type plate) of your
device.
The current spare parts list of the device can be
viewed online at http://www.wuerth.com/partsman-
ager. Alternatively, contact your local Würth agency
for a hardcopy.
Designation
Drive spindle [6]
Handle [1]
¼" bit [5]
ZEBRA Self-drilling screw,
®
DBS Pan Head belted
Assembly (fig. I)
Insert the screw bit [5] into the drive spindle [6]
■
and push back the connection piece of the
holding sleeve as shown in the illustration.
Insert the drive spindle [6] into the bit socket of
■
the screwdriver [2] and push forward the con-
nection piece of the holding sleeve.
Insert the drive spindle [6] with screw bit [5]
■
into the lance [3] with attached handle [1] and
attachment [4].
Tightly fasten the lance [3] to the screw-
■
driver [2] using the handle [1].
Tighten the setting screw of the clamp.
■
3 The device is now ready for use.
Prod. no.
0702 048 101
0702 048 102
0702 048 103
0200 148 20
