V. SPECIFICATIONS

MAIN UNIT

Model
Screw
driving
Capacity
Drilling
Motor
No load speed
Maximum torque
Maximum clutch torque
Overall length
Weight (with battery pack)

BATTERY PACK

Model
Storage battery
Battery voltage

BATTERY CHARGER

Model
Weight
Electrical rating
Charging time
NOTE:
• For applicable battery packs to this charger, see the label on the charger or the latest
general catalog.
The instruction label on the battery packs also shows the applicable charger.
Machine screw
Wood screw
For metal
LOW: 4.4 N·m (45 kgf-cm, 39 in-lbs)
HIGH: 1.5 N·m (15 kgf-cm, 13 in-lbs)
3.0 N·m (30 kgf-cm, 26 in-lbs)
3.6 V DC (3.6 V x 1 cell)
See the rating plate on the bottom of the charger.
2.4 V
9007450000
Full 45 min.
-13 -
1479120000
M2.5 – M5
ø 3.8 x 38 mm (5/32" x 1-29/64")
ø 5 mm (13/64") spc t = 1.6 mm
3.6 V DC
LOW: 200 min-1 (rpm)
HIGH: 600 min-1 (rpm)
276 mm (10-55/64")
0.5 kg (1.1 lbs)
1479110000
Li-ion Battery
9007460000
0.6 kg (1.3 lbs)
Full 30 min.
3.6 V
1479110000
