4. Technical specifications

Shockproof anti-static bars
Operating voltage:
Max. current from emitter
point to earth:
Max. temperature:
Max. operating distance:
Usual operating distance:
Non-shockproof anti-static bars
Operating voltage:
*1
Max. current :
Max. temperature:
Max. operating distance:
Usual operating distance:
*1 Limited by relevant power unit.
*2 Option: SS anti-static bars to 150 °C possible.
Operating conditions: Industrial

5. Installation

Warning:
- The electrical installation must be carried out by an electrical engineer with the
relevant training and qualifications.
- When carrying out work on the equipment: de-energise the equipment.

5.1. Checks

- Check that the anti-static bar is undamaged and that you have received the correct version.
- Check that the data on the packing slip corresponds with the data shown on the product
received.
If you have any problems and/or in the case of ambiguity:
Please contact Simco-Ion or your regional agent.
5.2. Installation
5.2.1. Summary
Fit the anti-static bar right before the location where static electricity is causing trouble.
In places where the material is neutralized, it should have a layer of air.
The correct distance from the anti-static bar to the material should be established by experiment
(see technical specifications).
Bars_UM_9752039010_NL_D_GB_F_V3_4
MEB / MEJ EP-SH-N
+/- 7 kV +/- 7 kV
20 A 20 A
55 °C. 55 °C.
30 mm 150 mm
25 mm 50 mm
SS
+/- 4 kV
3 mA
*2
55 °C.
30 mm
25 mm
P-SH-N P-SH-N2
+/- 7 kV +/- 7 kV
20 A 20 A
55 °C. 55 °C.
600 mm 150 mm
50 mm 50 mm
MaxION MSB-375
+/- 5 kV +/- 5 kV
30 A 10 A
70 °C. 50 °C.
400 mm 50 mm
50-80 mm 20 mm
