KENMORE ELITE MICROCLEAN 665.1481 Guide D'utilisation Et D'entretien page 17

Options
TurboZone
®
In the back of the lower rack, rotating jets
spray water into your casserole or other
dishes to eliminate the need for soaking and
scrubbing of dirty, baked-on food soils. For
your toughest items, use the TurboZone
option with the Pots & Pans cycle. See loading
information.
High Temp Wash
Raises main wash temperature to improve
cleaning for loads containing tough,
baked-on food.
Sani Rinse
Sanitizes dishes and glassware in accordance
with NSF International NSF/ANSI Standard
184 for Residential Dishwashers. Certified
residential dishwashers are not intended for
licensed food establishments. Only sanitizing
cycles have been designed to meet the
requirements of the NSF/ANSI 184
performance standard for soil removal and
for sanitization efficacy. There is no intention,
either directly or indirectly, that all cycles on
a NSF/ANSI 184 certified dishwasher meet
the NSF/ANSI 184 performance standard for
soil removal and for sanitization efficacy.
The Sani Rinse indicator indicates at the end
of the cycle whether the Sani Rinse option
was successfully completed. If the indicator
does not activate, it is probably due to the
cycle being interrupted.
Smart Dry™
Turns the heat element on at the end of the
wash cycle. Use rinse aid with or without the
Smart Dry™ option for best drying results.
Plastic items are less likely to deform when
loaded in the top dish rack.
Smart Dry™ Plus
Smart Dry™ Plus is used with Smart Dry™ to
extend the heated drying time. For the very
best drying performance, use rinse aid and
the Smart Dry™ Plus option.
Can be
selected with
H E
SmartWash
®
Pots & Pans
Normal Wash
®
H E
SmartWash
®
Pots & Pans
Normal Wash
H E
SmartWash
®
Pots & Pans
Normal Wash
Top Rack Only
Bottom Rack Only
Available with any
cycle except
Quick Rinse
What it does
Directs all of the cleaning
power of the dishwasher to
the TurboZone area during
®
certain times in the wash
cycle.
Raises the main wash
temperature from 120°F
(49°C) to 140°F (60°C).
Increases the main wash
temperature from 120°F
(49°C) to 140°F (60°C) and
the final rinse from 140°F
(60°C) to 155°F (68°C).
Turns the heat element on at
the end of the wash cycle.
NOTE: Each time you press
the Smart Dry Plus button it
toggles between the Smart
Dry , Smart Dry Plus, and
TM TM
the Air Dry options.
Smart Dry is selected when
TM
the light under the SMART
DRY PLUS button is lit.
Smart Dry Plus is selected
TM
when both lights, above and
below the Smart Dry Plus
button, are lit.
Air Dry is selected when both
lights are not lit.
The Smart Dry™ Plus option
must be selected for any cycle
and will momentarily flash for
cycles that do not allow it.
Added
Added time Water**
to cycle Gallons
(Liters)
0 to 2.6
0:05 to 2:00
(0 to 9.8)
0 to 2.6
0:00 to 0:30
(0 to 9.8)
0 to 2.6
0:10 to 2:00
(0 to 9.8)
0:11 to 0:48
0:42 to 1:20
0
17
