H
STEP 3
STEP 5
STEP 7
STEP 9
STEP 11
4
74
STEP 13
man_R233TC.indd 74
REPLACEMENT OF THE WICK
L
ENSURE THAT THE HEATER IS OFF AND COMPLETELY
COOL BEFORE STARTING TO REPLACE THE WICK.
1a. Open the tank cover  and remove the fuel tank .
1b. Remove the batteries to prevent possible burns.
STEP 2
1c. Open the front grille and remove the combustion cham-
1d. Remove the knurled wick adjustment knob 2 by pulling
2a. Unscrew the 5 screws, 1 from the back and 2 from the
2b. Remote the sensor at the back side of the cabinet .
STEP 4
3.
4.
5.
6a. Remove the automatic ignition assembly by unscrewing
6b. Remove the tip-over safety mechanism by unscrewing 2
STEP 6
7.
8.
9.
10. Install the new wick and insert the three pins on the
STEP 8
11. Push the new wick into the retainer teeth of the wick
12. Line up the pins with the slotted holes inside the wick
STEP 10
13. Turn the knurled wick adjustment knob 2 and check to
14. Slide the wick adjuster assembly down the draft tube.
STEP 12
STEP 14
ber 4.
it straight out.
right side and 2 from the left side of the cabinet .
Remove the cabinet by pulling it straight up.
Remove the 2 screws on the ignitor coil K.
Remove the wind cover A/B.
1 screw.
screws.
Unscrew 4 wing nuts.
Remove the wick adjuster assembly.
Press the pin of the wick which is assembled inside the
wick case assembly. Disassemble the wick, the wick
holder, the wick case assembly seperately.
new wick into the 3 holes on the wick sleeve in the
upward direction (See the arrow marked "up" on the
wick sleeve).
sleeve so that the wick adheres tightly around the inside
of the wick sleeve, smoothly without any wrinkles.
adjuster. Then lightly press each of the three pins of
the wick (now attached to the wick sleeve) towards the
inside. Insert the three pins into the slanted grooves
of the wick adjuster. Press on each of the three pins ,
inserting them securely in the holes.
be sure that the wick moves up and down freely.
Position the adjuster shaft to the front of the heater.
17-05-16 09:09
