HOW TO REMOVE THE FREEZER DRAWER
WARNING: Use two or more people to remove and
install the freezer drawer. Failure to do so can result in
back or other injury.
CAUTION: Do not hold the handle when removing or
replacing the drawer. The handle may come off and it
could cause personal injury.
NOTE: In the following figures, the Pullout Drawer
located above the freezer drawer is not shown for
clarity.
Pull the drawer open to full extension. Remove the
lower basket 1 by lifting the basket from the rail
system.
Remove the screws
2
2
Grasp the drawer on each side and pull it up to
separate it from the rails.
With both hands, slide each bar in simultaneously.
1
from the rail on both sides.
REFRIGERATOR INSTALLATION
HOW TO INSTALL THE FREEZER DRAWER
Pull out each rail to full extension.
Grasp the drawer on each side and hook drawer
supports 1 into rail tabs
Lower the door into its final position and tighten the
screws located on both sides.
3
3
With the drawer pulled out to full extension, insert the
lower basket in the rail assembly.
4
WARNING: If the Durabase divider is removed, there is
enough open space for children or pets to crawl inside.
To prevent accidental child and pet entrapment or
suffocation risk, DO NOT allow them to touch or go
near the freezer drawer.
WARNING: DO NOT step or sit down on the freezer
drawer.
15
2 located on both sides.
1
2
4
