Alpha 400 Handbook
Valid voltage ranges for @ and @/@ for each module are as follows:
Module
Voltage Range
A
@ = 4.5 – 5.5V
AA
@ = 4.5 – 6.5V
BB
@ = 4.5 – 6.5V
B
@ = 4.5 – 5.5V
C
@ = 5 – 16V
D
@ = 18 – 29V
E
@/@ = 5 – 16V / 5 – 16V
EB
@/@ = 4.5 – 5.5V / 4.5 – 5.5V
EQ
@/@ = 4.5 – 5.5V / 2.7 – 3.9V
F
@ = 9 – 16V
G
@ = 17.5 – 29V
H
@/@ = 18 – 32V / 18 – 32V
J
@ = 30 – 48V
Secondary Options:
Option
Description
_PA
Forces paralleled modules to share load current. Additionally it also provides the module
good signal.
_PP
Provides either of the following functions:
a) Reduces module current limit and caters for paralleled modules with busbar linking. For
use with modules providing a max output of up to 16V only; or
b) Identical to _PA except that the module is paralleled at the output of the module with
busbar linking.
_IN
Provides an external signal which may be used to inhibit the output of the module.
_RP
Provides remote programming of the module output voltage.
Note:
The RP option can only be used on modules with output voltages rated up to 16V.
Not for use with a module voltage range of 18-29V or twin output modules.
ELECTRICAL & THERMAL RATINGS:
Input parameters
NOMINAL INPUT VOLTAGE RANGE
MAX. INPUT VOLTAGE RANGE
INPUT FREQUENCY
MAXIMUM INPUT CURRENT
INRUSH CURRENT
Output parameters
CONFIGURATION
Configurations with one or more A, AA, R or T
modules
Configurations with one or more F modules
PSU's with Low Speed Fan (LSF) Option
PSU's with Reverse Air (RA) Option
Use of input/output connector mouldings
Use of input/output connector mouldings
Adjustment and Derating:
The Alpha 400 series is designed to provide a max output power of 400W at nominal output voltages. The following
procedure must be used to ensure the PSU is operated within its ratings:
a) Calculate user power for each module (volts x amps).
b) Add all the individual module powers together. The total power must not exceed the power rating of the
C converter 400W.
Module
Voltage Range
K
@ = 18 – 29V
L
@ = 1.8 – 3.2V
M
@ = 5 – 16V
N
@ = 18 – 32V
P
@/@ = 18 – 29V / 5 – 16V
Q
@ = 2.7 – 3.9V
R
@ = 2.7 – 3.9V
S
@ = 2.5 – 5.7V
T
@ = 1.8 – 3.2V
U
@ = 10 – 21V
W
@ = 4.5 – 5.5V
Z
@ = 4.5 – 5.5V
100 - 240VAC
90-264VAC
47-63Hz
7 AMPS
<50 AMPS
ORIENTATION
Vertical with airflow downwards
Vertical with airflow downwards
All, except vertical with fan at top
Horizontal only
All, except vertical with airflow
downwards
Vertical with airflow downwards
Page 15 of 26
MAX. AMPERE-
MAX. POWER
TURNS
350W
375W
155W
300W
80 + (3.2 x Vin)
14.7 + (3.67 x
Vin)
17128 issue 42, September 2018
80
80
30
60
80
80
