Alpha 1500 Handbook
may be followed by up to eight of any of the following:
@ followed by AA, A, BB, B, C, F, G, J, K, L, M, N, Q, R, S, T, U, W, or Z.
optionally followed by _MF, MFE, _X, _XL, MFL, MFU, MFV or _MFV, MFPF, _PA, _IN, _PP, _RP, RPA, RPB, RPC, RPD, _D,
_MG or _CD
or @/@ (where / may be replaced with _) followed by: E, EB, EQ, H, or P:
or B/S
Where @ and @/@ = applicable voltage range and the following one or two letters are the module type.
_MF, MFE = Mains fail option (may also be called X).
MFU = Mains fail option with uncommitted output connections.
MFV = Mains fail option with VME bus
MFPF = Mains fail, module parallel and PSU/fan inhibit
MFL, _XL = Mains fail latch
_PA, _PP, _IN, _RP, RPA, RPB, RPC, RPD, _CD and _MG = Secondary module options.
B/S = Blanking slot which occupies one 23mm slot.
Only up to eight 23mm slots may be filled up per unit, noting that all modules occupy one 23mm slot except for AA, A, F, G, J, K,
R, S and T modules which occupy two 23mm slots.
Valid voltage ranges for @ and @/@ for each module are as follows:
Module Voltage Range
AA @ = 4.5 – 6.2V
A @ = 4.5 – 5.5V
BB @ = 4.5 – 6.5V
B @ = 4.5 – 5.5V
C @ = 5 – 16V
D @ = 18 – 29V
E @/@ = 5 – 16V / 5 – 16V
EB @/@ = 4.5 – 5.5V / 4.5 – 5.5V
EQ @/@ = 4.5 – 5.5V / 2.7 – 3.9V
F @ = 9 – 15.5V
G @ = 17.5 – 29V
H @/@ = 18 – 32V / 18 – 32V
J @ = 30 – 48V
RATINGS & LIMITATIONS:
Max power & per converter
Max. Ampere Turns per converter
Max. Ampere Turns (total)
Max number of secondary windings per converter
Max Input Current
Input frequency range
Maximum operating altitude
Input Voltage
90 - 100VAC
100 - 264VAC
150-165VAC
165-180VAC
180-264VAC
85 - 264VAC
85 - 90VAC
* - 1000W for 30 seconds maximum followed by 800W for 60 seconds minimum.
For units with MFPF option, the input voltage range is limited to 180-264Vac only
There are two converters in the psu: one for module slots 1-4 and the other for slots 4-8.
The above ratings apply for all PSU permitted mounting orientations. The ratings also apply whether or not input and/or output
connector housings are fitted.
Module
K
L
M
N
P
Q
R
S
T
U
W
Z
858W
138
260
10
16A
47 - 63Hz
3000m
Intermittent Output
Power Rating
-
-
-
-
-
-
1000W *
Page 14 of 21
Voltage Range
@ = 18 – 29V
@ = 1.8 – 3.2V
@ = 5 – 16V
@ = 18 – 32V
@/@ = 18 – 29V / 5 – 16V
@ = 2. 7 – 3.9V
@ = 2. 7 – 3.9V
@ = 2.5 – 5.7V
@ = 1.8 – 3.2V
@ = 10 – 21V
@ = 4.5 – 5.5V
@ = 4.5 – 5.5V
Continuous Output
Power Rating
1000W
1000W
1500W
1595W
1690W
800W
-
Maximum Ambient
Temperature
45°C
50°C
50°C
50°C
50°C
50°C
50°C
