poor signal-noise ratio will result, then adjust
a higher value with the key
4) Memorize the adjustment by pressing the key
SET. The display shortly indicates
adjusting mode is exited, the unit returns to
normal operation.
5.3 Locking/unlocking the unit
With the unit locked it is not possible
a to switch off the unit; if the power switch (4) is
set to OFF with the unit locked, the display
shows .
b to recall the adjusting modes for frequency
and sensitivity.
5.3.1 Activating the lock function
1) First recall the frequency adjusting mode:
Keep the key SET (8) pressed for 2 s.
2) As soon as the indication MHZ flashes in the
display, shortly press the button SET to
change into the sensitivity adjusting mode.
3) As soon as the display indicates the sensitiv -
ity, shortly press the key SET to change into
the lock mode:
(locking deactivated).
4) Press the key (10):
display.
5) Memorize the adjustment by pressing the
key SET. is shortly displayed, the ad-
justing mode is exited, the unit returns to nor-
mal operation.
5.3.2 Deactivating the lock function
1) The power switch (4) must be set to ON.
2) Keep the key SET (8) pressed for 3 s until
flashes in the display.
3) Press the key (9):
display.
4) Memorize the adjustment by pressing the
key SET. is shortly displayed, the ad-
justing mode is exited, the unit returns to nor-
mal operation.
All rights reserved by MONACOR
may be reproduced in any form or by any means for any commercial use.
(10).
, the
flashes in the display
flashes in the
flashes in the
® INTERNATIONAL GmbH & Co. KG. No part of this instruction manual
6 Replacement Microphone
Cartridges
The following replacement microphone cartrid-
ges of the product range from "img Stage Line"
are available:
Type MD-872 (order no. 23.3440)
capacitor microphone cartridge with super-
cardioid directivity and extended frequency
range (50 – 18 000 Hz)
7 Specifications
Type of unit: . . . . . . . . . dynamic hand-held
Directivity: . . . . . . . . . . hypercardioid
Radio frequency range: 863.125 – 864.875 MHz
Audio frequency range: 50 – 16 000 Hz
Frequency stability: . . . ±0.005 %
Transmitting power: . . . < 10 mW (EIRP)
Ambient temperature: . 0 – 40 °C
Power supply: . . . . . . . two 1.5 V batteries
Dimensions: . . . . . . . . . ∅ 50 mm × 260 mm
Weight: . . . . . . . . . . . . 350 g
Subject to technical modification.
microphone with
PLL multifrequency
transmitter
size AA (R6)
