B
or no camera image is visible on the mobile unit
when operating with the power supply unit,
B
then: switch the mobile unit on by pressing the on/off
button [8]
B
or reduce the distance between the mobile unit and
the door intercom.
If the system is still not working as expected, even when the
devices are next to one another, they must be paired again (see
section 13.2 "Register").
#
The strength of the incoming wireless signal is displayed by the
symbol on the top right of the camera image on the screen
[6]. The bars next to the antenna symbol indicate the strength.
#
A symbol on the top left of the camera image on the screen
indicates whether the door intercom showing the camera image is
being supplied with power by the power supply unit (
batteries ( ) .
#
If there is a ring on the outdoor station and a snapshot is saved but
the conversation is not accepted on a mobile unit, the flashing red
symbol at the top left of the screen indicates that a new
snapshot has been taken. The images of missed visitors can be
viewed in the "Snap Show" menu item, and the symbol
disappears.
#
Transmission of sound is only available while the talk function is
activated.
11.2 Switching on the outdoor station camera image
manually
!
With the mobile unit switched on, press any button
[1/2/3/5/7/8] to make the start screen [6] appear.
!
—
Press the right button
paired outdoor station, its camera image appears automatically;
with two paired outdoor stations, use the
select the outdoor station required, confirm by pressing the left
—
button [3 - "Select"] and the camera image appears.
As long as the camera image is visible, the following options are
available:
!
To take a static image and save it on the mobile unit, press the
—
right button [7]; the
!
By pressing the talk button [1], you can activate the conversation:
either the sound from the microphone [21] on the outdoor station
can be heard over the loudspeaker [10] on the mobile unit or the
sound from the microphone [4] on the mobile unit can be heard
over the loudspeaker [18] on the outdoor station in alternation
(intercom function).
The conversation can be ended by pressing the on/off button
[8]; otherwise, it ends automatically after approx. 45 seconds,
the start screen appears again and the screen goes off after
approx. 20 seconds.
!
Pressing the door release button
door release, the start screen appears again and the screen
switches off after approx. 20 seconds.
[7 - "Mon" (Monitor)]. With only one
and [2] buttons to
symbol appears briefly.
[5] activates a connected
!
To switch the camera off again, press the on/off button
otherwise, this happens automatically after approx. 45 seconds,
the start screen appears again and the screen switches off after
approx. 20 seconds.
Note:
When operating the outdoor station with batteries, it is
not possible to switch the camera image on manually
the intercom is supplied in
appears on the black screen. (In energy-saving mode, the camera
image is displayed only when the doorbell button [25] is pressed).
If you still wish to be able to switch the camera image on manually,
you have to switch the outdoor station to
(please note: in this case, the batteries in the outdoor station will go
flat significantly more quickly):
) or by
!
Press the pairing button [27] on the outdoor station until you hear
a long beep
!
Press the pairing button a second time until you hear
beeps .
To return to energy-saving mode,
!
press the pairing button [27] on the outdoor station until you hear
three short beeps
!
Press the pairing button a second time until you hear
12. Optional addition of a DVT60M
mobile unit, a DVT67M monitor
and/or a DVT60T / DVT60T2 outdoor
station
DVT60 SET
The mobile unit of the DVT60 SET has already been paired with the
door intercom on channel No. 1. A maximum of
and/or one more outdoor station
system.
To establish a wireless connection between a DVT60T outdoor station
and a DVT60M mobile unit or a DVT67 monitor, pair them as follows:
!
The outdoor station and mobile unit must both have a power
supply and the mobile unit must be switched on.
!
Press any button [1/2/3/5/7/8] on the mobile unit to make the
start screen appear.
!
Press the left button
!
Scroll through the menu with the
reach "Register" and press the left button
You can select between outdoor station of the set (channel no. 1)
or a second outdoor station (channel 2).
!
Move the hash # to the channel you require by pressing
/ [2]:
#
To connect an additional mobile unit / a monitor to the
outdoor station of the set, select channel No. 1.
#
To connect a mobile unit to a second door intercom, select
channel No. 2.
energy-saving mode
energy consumption mode
.
.
can be connected to the existing
—
[3 - "Menu"] to open the menu.
and [2] buttons until you
[8];
as
. Only "Monitor"
three short
a long beep .
one more mobile unit
—
[3 - "Select"].
