4.5 - 0-10v Control
Thermal load
(P150 = 1)
Setpoint command
(P150 = 2)
note: The graphs referring to the parameters of zone 1 are the same for zone 2 with the corresponding parameters.
Return water
setpoint
P105
P130 (setpoint)
Y+Z
Z = P151 * (0-10V)%
Y
P106
P120 X
Return water
setpoint
P105
Y
P106
0V
Return water
setpoint
P132
Y
P131
0V
11
Example:
P151 = 5°C
0-10V signal = 6V = 60%
Z = 5°C * 60% = 3°C
Outdoor air
temperature
P121
HEATING
P130 (setpoint)
X
10V
COOLING
P130 (setpoint)
X
10V
0-10V
0-10V
