2.3 INSTALLATION INSTRUCTIONS:

TOOLS REQUIRED:

➭ A Phillips screwdriver.
PROCEDURE:
1. Unplug the refrigerator.
2. Remove the cover from the top hinge. (Fig.1)
3. Loosen the top hinge screws. (Fig.1)
4. Take the door off with an upward movement.
5. Remove the cover of the central hinge screws,
and loosen the two screws holding it in place.
(Fig.2)
6. With the screws loose, move the freezer door
upward to release it.
7. Lastly, remove the screws and take out the bot-
tom hinge. (Fig.3)
8. Change the position of the bottom hinge shaft,
placing it on the opposite side. (Fig.3)
9. If fitted, change the lateral handles to the other
side.
10. Reverse this procedure to refit the doors.

2.4 BEFORE FIRST USE:

➭ Clean the inside with warm water and baking soda. Rinse carefully and allow to
dry completely.
➭ Wait for 2 hours before starting to ensure that the motor lubricants have stabi-
lized.
➭ If the refrigerator has been switched off, wait 4 hours after restarting before plac-
ing food inside.
5
Fig. 1 Top hinge
Fig. 2 Central hinge
Fig. 3 Bottom hinge
