Installation Instructions – RSRK
INSTALLATION
Items Required
Screwdriver
●
●
Safety Glasses
●
●
Gloves
●
●
Drill with ¼ nut driver
●
●
Wire Cutters
●
●
Installation Instructions
1.
Remove the lamps from the luminaire. (Figure 1.)
Housing
Figure 1.
2.
Remove the sockets and socket tracks from fixture.
(Figure 2.)
Socket Track
Housing
Figure 2.
2
COOPER LIGHTING SOLUTIONS
Lamps
Sockets
IB519095EN
Installation instructions
3.
Align and install new Retrofit End brackets using 2 self-
tapping screws. (Figures 3 and 4.)
Housing
Figure 3.
Housing
Figure 4.
Retrofit End Bracket
Self-Tapping Screws
(2 Nos/Bracket)
