DD52R-E-RF
7. Operating mode
7.1 Absolute / incremental measuring mode selection
Press the key to select the absolute or incremental measuring mode.
The measuring mode selected is shown on the display by the symbols:
- ABS : absolute measuring mode
- REL : incremental measuring mode
_ _ _ 0 _ _
The available options are:
- ArCLr (default): passing from ABS to REL the counter is set to zero.
- Ar : passing from ABS to REL the counter is not set to zero. In this case, the
counter is set to zero by pressing
- OFF : the key
measuring mode.
To program the parameters listed above, see paragraph 8.2.

7.2 Unit of measure selection

Press the key to select the unit of measure needed. The options available
are millimeters, inches and degrees.
The measuring mode selected is shown on the display by the symbols:
- mm : millimeters
_ _ _ _ _ 0
EN
20
It is possible to change the key function by setting the
parameter _ _ _ 0 _ _
is disabled and does not allow changing the selected
- INCH : inches
It is possible to change the key function by setting the
parameter _ _ _ _ _ 0
Electronic position indicators
Data transmission via radio frequency
+ .
- D : degrees
