Installation; Handling - S&P CACB-N Notice Technique

Cabinet fan fixing
Ø11
L
Model
CACB-N 05
CACB-N 08
3.

INSTALLATION

3.1 Handling

3.2 Installation
The box must be attached to a flat support by the side holes provided for this purpose. It is recommended
to install it on vibration absorbers and connect it with flexible sleeves.
The CACB-N can be installed either for horizontal discharge or for vertical discharge by simply flipping the box.
Horizontal
discharge
Rejet Horizontal
ENGLISH
K
M
K L
479 350
479 400
Unpack the box.
To lift it, attach the box with 2 slings to the fixing straps located around
the discharge branch.
Vertical
discharge The air tight installation of this box and its network should satisfy the
Rejet Vertical
technical conditions defined in DTU 68-3.
Important : Make sure that the motor's square cooling holes (located
under the electric connection box) are not obstructed.
P
Ø11
N
Dimensions
(mm)
M
98
98
11/20
K
N P
175 62
250 75
