Remplacement De La Pile / Replacing Battery - JRI Mini SPY Green Manuel D'utilisation

FEATURES
FEATURES
Measurement range
Number of channels
Remote sensor
Type of input
Accuracy
Recording interval
Memory size
Operating conditions
Temperature for storage
Radio range (in free field)
Radio band
Battery lifetime
Dimensions
Protection level
CE ERM conformity
EN 12830 conformity
V. REMPLACEMENT DE LA PILE / REPLACING BATTERY
When the Mini SPY RF Green battery has to be replaced, a technical alarm is processed by the software Sirius
DOWNLOAD THE SPY RF MEMORY BEFORE CHANGING THE BATTERY. DO NOT WAIT
UNTIL THE BATTERY IS EMPTY OTHERWISE THE MEMORY WILL BE DELETED
To replace the battery, follow the instructions below :
1
Open the MiniSpy
RF Green
KEEP THE BATERY FAR FROM THE FIRE ; DO NOT TRY TO RELOAD OR TO SHORT CIRCUIT IT. USE ONLY BATTERIES
SUPPLIED BY JRI (REF 10102)
Restart the device by pressing 5'' on the pushbutton after changing the battery
©JRI Maxant
2
Replace the battery
Mini SPYRF GREEN
-40 +85°C
1 internal or external probe
Ø4 x50mm / 1m Cable
PTC
±0,4°C from -20 à +30°C
±0,5°C from -40 to -20°C & +30 to +80°C
±0.7°C above +80°C
1sec to 90 min
10 000 measurements +1ko
-30 +70°C
-40 + 85°C
Max 58 m adjustable
868MHz or 902MHz
2 years
85x55x18mm
IP67
EN 301 489 / EN 61000 / EN 61010
EN 55022 / EN 300 220
OK
3 4
Short circuit the two pins
with a paper clip to reset
the device
5
Replace the seal and
close the device
17
