PROGRAMMING FLOWCHART
Assign a
Change
User Code
Master code
Press (0)
Press (0)
+
Memory position
Memory
from 01 to 99
position (00)
Keypad
Proximity
Reader
Reader
Present Card/Tag
before the Reader*
Notes
Memory Position for User Code is always 2 digits
* no need to validate with A
Assign Examples
Ex.1: To assign User Code "12345" at Memory Position "5" and Relay 1 (2A) in Latch Mode assuming Master Code = 000
Press 000B + 0 + 05 + 12345 + A + 7 + 05 + 1 + A + 1 + 00 + A + B.
Ex. 2: To assign User Code "6789" at Memory Position "6" and Relay 2 that activates for 5 seconds assuming Master Code = 000
Press 000B + 0 + 06 + 6789 + A + 7 + 06 + 2 + A + 2 + 05 + A + B.
www.xprgroup.com
Enter "Master Code" OR "000" (if first time use)
1 small beep + 1 long beep + Yellow LED is 'on'
Assign Output
Press (7)
+
+
Memory position from
(01 to 99)
+
Press (1) for Relay 1
And/Or
Press (2) for Relay 2
And/Or
Press (3) for Relay 3
And/Or
Press (4) for Relay 4
Enter new code
(1 to 8 digits)
Start
Validate by pressing (B)
Multiple small beeps
No
Validation OK?
Yellow LED blinks rapidly
Yes
Set Output Timer
Pulsed Mode (01 to 99 sec):
Relay 1 : Press 1
Relay 2 : Press 2
Relay 3 : Press 3
Relay 4 : Press 4
+
01 to 99
Or
Latch Mode (ON/OFF):
Press (1) or (2) or (3) or (4)
+ (00)
Press A to validate
Validation
No
OK?
Yes
Press B (Yellow LED is 'off')
End
1
+
Assign Relay to
Delete
Exit Button
Single Code
Press (9)
Press (5) for PB1
Press (6) for PB2
Memory position
+
from (01 to 99)
Press (1) for Relay 1
And/Or
Press (2) for Relay 2
And/Or
Press (3) for Relay 3
And/Or
Press (4) for Relay 4
DINMTPX-MF v.2
Delete
All Codes
Press (8)
+
+
(99)
6
