Troubleshooting

In case of any trouble with this unit, please
take the time to look through this chart and
see if you can solve the problem yourself
before you call your Dealer or a TEAC service
center.
No power.
e If the batteries are fully discharged,
connect the AC adaptor to recharge the
batteries.
No sound.
e Turn the unit on and adjust the volume.
The sound is noisy.
e The unit is too close to a TV set or
similar electronic appliances. Install the
unit further from them, or turn them
off. Also try a different electrical outlet
or use your R-1 on battery power to see
if the noise is coming from your
electrical connection.
Cannot listen to any station, or signal is
too weak.
e Tune in the station properly.
e Transmitting station is too far away.
e Rotate the unit or antenna for the best
reception position.
Maintenance
If the surface of the unit gets dirty, wipe
with a soft cloth or use diluted neutral
cleaning liquid. Be sure to remove any
fluid completely. Do not use thinner,
benzine or alcohol as they may damage
the surface of the unit.

Specifications

Frequency Range (FM):
87.50 MHz to 108.00 MHz
Frequency Range (AM):
520 kHz to 1,710 kHz
(U.S.A./Canada model)
522 kHz to 1,620 kHz
(Europe model)
Speaker Type:
65 mm (2 1/2")
Impedance:
4 ohms
Output Power:
1.5 W
Power Requirement (AC adaptor):
120 V, 60 Hz (U.S.A./Canada model)
230 V, 50 Hz (Europe model)
Power Consumption:
15 W
Dimension (W x H x D):
238 x 127 x 134.5 mm
(9 3/8˝ x 5 ˝ x 5 5/16˝)
Weight:
1.4 kg (3 1/16 lbs)
Standard Accessories:
AC Adaptor x 1
FM Lead-type Antenna x 1
Stereo mini plug cable x 1
Owner's Manual x 1
Warranty Card x 1
< Design and specifications are subject to
change without notice.
< Illustrations may differ slightly from
production models.
