Do not use the battery as a power source for other unspecified appliances.
The appliance is designed for professional use and may be operated,
serviced and maintained only by trained, authorized personnel.
personnel must be informed of any special hazards that may be encountered.
The appliance and its ancillary equipment may present hazards when used
incorrectly by untrained personnel or when used not as directed.
The appliance may be operated only when connected to an electric supply
providing a voltage and frequency in compliance with the information given
on its type identification plate.
3.2 Items supplied as standard
1 Charger
1 Operating instructions
3.3 Charge status of the Liion battery during charging
LEDs light constantly
LED 1,2,3,4
LED 1,2,3
LED 1,2
LED 1
-
4 Technical data
Right of technical changes reserved.
Charger
Cooling
Battery
Output voltage
Weight of appli-
ance
AC supply voltage for
C 4/3690
AC supply frequency
Printed: 18.01.2016 | Doc-Nr: PUB / 5069440 / 000 / 09
LEDs blink
-
LED 4
LED 3
LED 2
LED 1
C 4/3690
Cooling by con-
vection
Li-ion
7.2...36 V
0.6 kg
100...127 V
50...60 Hz
Charge status in
%
= 100 %
75 % to 100%
50 % to 75 %
25 % to 50 %
< 25 %
C 4/36350
Fan-assisted
cooling
Li-ion
7.2...36 V
1.1 kg
220...240 V
50...60 Hz
This
2
C 4/36DC
Cooling by con-
vection
Li-ion
7.2...36 V
0.6 kg
19
en
