ADDITIONAL FEATURES OF VZ-7D
Infrared remote control
One of the unique features of WolfVision's portable Visualizers is that there are only 5
buttons on the unit. Therefore anyone can use it without any instructions. For more
experienced users there are some additional functions on the remote control:
ZOOM
The Zoom keys are the most important keys on the IR-
remote control. That is why they stand out in white
color. ZOOM keys are also on the camera head of the
Visualizer.
FOCUS (manual)
When the Focus keys are pressed the Visualizer
switches off the autofocus function.
The next time the zoom keys are pressed the
autofocus is switched on again.
IRIS (manual brightness adjustment)
When the Iris keys are pressed the Visualizer switches
off the auto iris function.
The next time the zoom keys are pressed the auto iris
is switched on again.
PRESETS (pre-programmable camera settings)
Two zoom positions and camera settings can be recalled by quickly (!) pressing the Preset 1
or Preset 2 key. A user has the opportunity to store his own presets. By pressing one of the
Preset keys for more than 3 seconds, the present camera and zoom settings are stored as a
preset. Please note that if the Visualizer is not used for a long time the factory presets
reappear when the unit is switched on again.
IMAGE on / off
The Visualizer's image output by the video output (12) or Y/C-output (13) can be switched on
and off with these keys. There is absolutely no monitor image distortion when switching on
and off, because the Visualizer actually outputs a black signal in the off position.
Changing the batteries
If the VZ-7D can only be controlled from a
close distance or if it cannot be controlled at
all with the infrared remote control you may
have to change the battery.
Open the cover of the remote control with a
flat object (for example a coin or a big
screwdriver) and replace the two 1.5 V AA
batteries with new ones.
6
