ASSEMBLY INSTRUCTIONS

Before Assembly
The Model 4024 ProPlus® Scale is shipped disassembled in one box. Carefully inspect the
shipping carton for shipping damage before unpacking. If damage is found, contact your shipper
or Health o meter® Professional representative immediately. Claims must be filed with the
shipper as soon as possible after receipt of the damaged package. Remove each assembly from
the carton and unwrap packing material carefully to prevent scratching the unit's parts. To avoid
damaging the scale parts when unpacking it, do not use a box cutter, knife, scissors or
any sharp object to open the packaging.
Parts List:
(1) Scale Assembly
(1) User information
(1) Box Containing:
(1) Display Assembly with attached Load Cell Cable
(1) Small Box Containing:
(1) Power Adapter
(8) Feet (Feet Assemblies)
Tools required: Phillips screwdriver (not included)
Figure 1 - Assembly of the 4024
5
