Installation
1. Fit clamping bracket to the power supply unit, and to the controller.
2. Clamp controller to the siphon pipe. Connect Bluetooth adapter, if it is used, and HF sensor to the controller.
3. Route the solenoid valve cable and power supply of controller (and Bluetooth cable when using the Bluetooth
adapter) downwards through the inspection opening.
For mains model: Connect to 220V mains,
power supply unit down through the inspection opening.
4. Attach urinal to the wall. Connect urinal flushing system incl. power supply unit/battery compartment,
"Connection diagram", page
5. Push cable carefully upwards into the urinal.
We recommend that the cable outlets of the housing (which is to be pushed in) face forwards.
6. Push the power supply unit or battery compartment through the inspection opening and attach it to the si-
phon tube using the clamping bracket.
Ensure that the cables are no longer visible.
7. Before opening the connected water line, you must ensure that the urinal control system has previously been
commissioned for a minimum of 30 seconds (power connection). This applies to the battery and mains versi-
ons.
S. 55
see "Connecting to the mains power supply", page
Advice!
If no Bluetooth adapter is mounted:
Before mounting the urinal, connect the urinal flushing system to the power supply
for test purposes, and if necessary adjust the settings on the controller; see separate
operating instructions.
51.
52. Route
see
