Installing the Rack Stabilizer Feet

WARNING:
installed could cause the rack to tip over, potentially resulting in bodily injury
under certain circumstances. Therefore, always install the stabilizer feet before
installing components in the rack.
Install the stabilizer feet on the rack as follows:
1 Install the front and side stabilizer feet on a standalone rack.
2 Install the front stabilizer feet on all racks in a suite and install the
stabilizer feet on the sides of the rack at each end of the suite.
Installing the Front Stabilizer Feet
1 Open the front door.
NOTE:
The stabilizers are located in an accessory box that is shipped with the rack
enclosure.
2 Position each front stabilizer foot against the base of the rack frame and
align its holes with the corresponding holes in the frame.
3 Using a 6 mm Allen wrench, secure each foot of the rack using the bolts,
washers, and cage nuts. See Figure 17.
Installing systems in a rack without the front and side stabilizer feet
