6 Rotate the window.
Place the door down on the floor.
a
Using a 10 mm wrench, remove all the nuts that secure the window to
b
the front door. See Figure 13.
NOTE:
surface in order to minimize risk of scratching the window and the Dell badge.
Remove the top and bottom end caps and slide the window out
c
through the top or bottom end of the door. See Figure 13.
NOTE:
same side of the door as the handle.
Rotate the window and slide it back into the door such that the badge
d
is now located at opposite end of the door.
Install the top and bottom end caps and install all the nuts that secure
e
the window to the front door. See Figure 13.
Figure 13. Rotating the Front Door Window
1
nuts
3
window
26
Installation Guide
It is recommended that you place the door on a smooth and clean
While reinstalling the window, ensure that the Dell badge is on the
1
2
end caps (2)
2
3
