Safety Notes

Gloves should be worn during installation to prevent

crushing and cutting injuries.
The shower system may only be used for bathing,

hygienic and body cleansing purposes.
Children as well as adults with physical, mental

and/or sensoric impairments must not use this
shower system without proper supervision. Persons
under the influence of alcohol or drugs are prohibi-
ted from using this shower system.
Do not allow the streams of the shower touch sen-

sitive body parts (such as your eyes). An adequate
distance must be kept between the shower and you.
The arm of the shower head is intended only to hold

the shower head. Do not load it down with other
objects!

Installation Instructions

• The fitting must be installed, flushed and tested after
the valid norms!
• Where the contractor mounts the product, he should
ensure that the entire area of the wall to which the
mounting plate is to be fitted, is flat (no projecting
joints or tiles sticking out), that the structure of the wall
is suitable for the installation of the product and has
no weak points. The enclosed screws and dowels are
only suitable for concrete. For another wall construc-
tions the manufacturer's indications of the dowel
manufacturer have to be taken into account.
• The filter insert must be use to protect the shower
against incoming dirt by pipework. Incoming dirt
leads to defects or/and can damage parts of the
shower; such caused faults voids all liability and
guarantee claims.

English

Technical Data

Operating pressure:
Recommended operating pressure:
(1 MPa = 10 bar = 147 PSI)
Hot water temperature:
Wall mount see page 33
Ceiling mount see page 35
Do not use silicone containing acetic acid!
Dimensions (see page 31+32)
Flow diagram (see page 31+32)
Spare parts (see page 40)
Cleaning (see page 36)
max. 0,6 MPa
0,1 – 0,4 MPa
max. 60°C
