Temperature sensor
BFT _ _ _ _-_ _003-_ _ _A0C-_ _

Configurable parameters

Parameters Description
SP1/SP2 Hysteresis function: Switchpoint for switching output (1 or 2)
FH1/FH2 Window function: Window high for switching output (1 or 2)
RP1/RP2 Hysteresis function: Reset point for switching output (1 or 2)
FL1/FL2 Window function: Window low for switching output (1 or 2)
EF Expanded programming functions
RES Reset the set parameters to the factory default settings
DS1/DS2 Switching delay which must be present continuously until an electrical signal change takes place
(SP1 or SP2)
DR1/DR2 Switching delay which must be present continuously until an electrical signal change takes place
(RP1 or RP2)
OU1 Switching function for switching output (1 or 2)
OU2 HNO = Hysteresis function, normally open
HNC = Hysteresis function, normally closed
FNO = Window function, normally open
FNC = Window function, normally closed
UNIT Change units
SETR Measurement range scaling (analog output)
4mA or 0V specifies at which temperature the output signal should be 4 mA or 0 V.
20mA or 10V specifies at which temperature the output signal should be 20 mA or 10 V.
OFS Offset setting (3% of the span)
DISM Display value in display mode
ACT = actual temperature value; LOW, HIGH = minimum, maximum temperature value OFF = display off;
SP1/FH1 = Function of switchpoint 1, RP1/FL1 = Function reset switchpoint 1,
SP2/FH2 = Function of switchpoint 2, RP2/FL2 = Function reset switchpoint 2
DISR Rotate display 180°
RHL Clear minimum and maximum value from memory
PAS Password entry, 0000 = no password, password entry digit by digit
TAG Enter a 16-digit alphanumeric measuring location number
