SETTING THE
Important: In the event of a power failure, wait 3 to 5 minutes before restarting.
TEMPERATURE
• To switch the display between the Fahrenheit (°F) and Celsius (°C) scale, depress the 'Set Upper' and 'Set
Lower' control buttons simultaneously for approximately five (5) seconds.
• The temperature range can be set as low as 39°F (4°C) or as high as 64°F (18°C) to suit your specific wine
storage requirements. Each depression of the 'Set Upper' or 'Set Lower' button will allow you to adjust the
temperature in 1° increments within the aforementioned range.
• You may view your 'set' temperature at any time by briefly depressing either the 'Set Upper'or 'Set Lower'
button.

WINE STORAGE

In order to achieve the maximum storage capacity of fifty (50) bottles, it will be necessary to position 4 bottles
on the top shelf as in Fig. A.
Next, arrange 8 bottles on the second to the sixth shelf, alternately as shown in Fig. B.
Finally, arrange 6 bottles on the bottom shelf as in Fig. C; this will allow for the total storage of fifty (50)
750mL wine bottles.
Fig A
SHELF
INSTRUCTIONS
To remove a rack from its locked position, tilt the rack as shown in Fig. D and pull
outward
To re-install, ensure the rack is resting securely on the support brackets and push the
rack inward until it locks into place.
OPERATING INTRUCTIONS (cont'd)
The Maximum Capacity* of the DWC508BLS is 50 (750mL) wine bottles.
* When stocked as per instructions below.
IMPORTANT!
Do not cover any part of the shelves with aluminum foil or any other material that
will prevent adequate air circulation within the cabinet.
Fig B
5
Fig C
Fig. D
