Trouble shooting

______________________________________________________________________

Error codes

If an error occurs, a warning signal sounds and the machine will stop.
Now you can see an error code on the display. By dint of the following table you can
identify the reason and solve the problem.
Error code
A
Counterfeit (UV)
b Counterfeit (MG/IR)
E Double
d Different size
E - 02 to
Damaged component
E - 08

Maintenance

______________________________________________________________________
As the machine is exposed to wear it is advisable to clean the device professionally. hbw cash solutions
offers services for that. Feel free to contact the technical support of hbw cash solutions.
As the operating mode of the machine is based upon sensor technology, do not expose it to direct solar radiation.
hbw cash solutions can take no liability for counting and sorting out different or counterfeit notes, as well as for
the value counting. The banknotes are feeded by a roller friction system. Therefor no nails, paper clips, hairs and
other small parts should reach the interior of the machine.
Before cleaning the machine the power supply has to be disconnected unconditionally!
Clean the device exclusively with a dry brush, the compressed air* cleaner B8 or the special cleaner R 605 of hbw
cash solutions.
(*alternative: Compressor with dry / oil free air. Max. 4 bar)
Please never clean the device with chemical cleaner.
Improper treatment leads to loss of warranty!
Technical specifications
______________________________________________________________________
Ambient temperature
Relative humidity
Hopper capacity
Stacker capacity
Banknote size
Display
Counting speed
Power supply
Power consumption
Dimensions (w x h x l)
Weight
Technical specification is subject to change without notice.
Error Possible reason
Abnormal banknotes detected.
(suspect note...).
Abnormal banknotes detected.
(suspect note...).
More than one banknote was
recognized at the same time.
Abnormal banknote by size was
detected.
Remove the concerned banknote and
count all notes again.
Remove all banknotes from the
stacker and count all notes again. If
necessary, please adjust the adjusting
screw.
Please check the abnormal banknote
and count all the notes again.
Please appeal to the technical sup-
xxx
port of hbw cash solutions.
0 - 40 °C / 0 - 104 °F
40 - 90 °%
approx. 150 notes
approx. 150 notes
min. 50 x 110 (mm)
max. 90 x 190 (mm)
8 - digit LED - Display
4 - digit LED - Display
approx. 1.000 banknoten / minute
230 VAC / 50 Hz
approx. 75 W
300 x 180 x 240 (mm)
7,00 kg
solution
