MAINTENANCE

6.5 INFORMATION FOR SERVICE CENTRES

Below is a list of specifications for machine adjustments and instructions for disman-
tling and replacing the blades.
WARNING!
!
only. Remove the ignition key before doing any adjustments or maintenance.
6.5.1 A
DJUSTMENTS
Element
a) Brake:
a
➤
Mechanical
transmission:
a
➤
Hydrostatic
transmission:
b) Drive:
a
➤
Mechanical
transmission:
a
➤
Hydrostatic
transmission:
c) Blade engagement:
a
➤
Lever
engagement:
a
➤
Electromagnetic
engagement:
These operations must be carried out by a specialized Centre
Position Position of controls
B
4.5
B
4.5
A
4.5
A
4.5
4.7.1
B
EN
Adjustment
47,5-49,5
45-47
114-116
109-111
Mod. 102 = 94-96
Mod. 122 = 92,5-93,5
Mod. 102 = 113-115
Mod. 102 = 90-91
41
