Spare Parts List - Adalit L2000-L Instructions D'utilisation

CODE
Torch
L2000-L
LB.2001.L
LB.19
LB.62
LB.63A
209
LB.2002.L
LB.2.A
LB.7
LB.9
LB.15
LB.16
206
300
306
307
LB.61
LC.10
LC.11
LC.13
318
3190
3220
321
323
324
325
333
339
332.LD
332.LD.10
33.LDT
34.LDT
3490.L2L
3260.LDL
114
LB.14
LB.23
LB.1005
Charger Spare parts
ADALIT L2000 Chargers
MAINS
CHARGER
Connection
at 100-240 V
VEHICLE
Connection
at 12 V
VEHICLE
Connection
at 24 V

2 - Spare parts list

DESCRIPTION
L2000-LB
LB.2001.LB Torch body.
LB.19 Retention washer.
LB.62 Tightening ring.
LB.63A Tightening ring.
209 Closing screw.
LB.2002.LB Complete lid.
LB.2.A Lid.
LB.7 Turning devise.
LB.9 Fastening hook.
LB.15 Turning axle.
LB.16 Screw for axle.
206 Rubber piece.
300 Focus shell.
306 Closing ring.
307 Protection glass.
LB.61 Tightening ring for closing ring.
LC.10 Closing screw.
Screw.
Screw.
318 Contact screw.
3190 Switch.
3220 Switch contact.
321 Switch contact.
323 Allen screw.
324 Switch positioner.
325 Switch washer.
Distance piece.
339 Sleeve.
LA.037 3 x 8 Allen screw.
361.E 3 x 12 Allen screw.
Main Optics.
Auxiliary Optics.
LB.57 3.6V 3.6W halogen bulb.
Setting tube.
Optics holder.
24307.G Projector.
3490.L2 Cable.
3260.L Bulbs socket.
359.E Central bulb fixing nut.
355.E Cap.
360.E Auxiliary bulb tightening piece.
114 "O" ring for closing switch axle.
LB.14 Switch rubber cover.
LB.23 M4 x 7 screw.
LB.1005 Hook for the head.
MC.02 Charger circuit card.
LB.3.V Charger shell.
LB.11 Charger base.
LB.92 Fixing piece for single vehicle charger .
Charger Code
C.1000
C.3000
C.5000
Charger Code
CV.1000.12V
CV.3000.12V
CV.5000.12V
Charger Code
CV.1000.24V
CV.3000.24V
CV.5000.24V
Type
Single
LB.84.C at 100/240V
For 3 torches
For 5 torches
Type Connection with Fuse. Code
Single
For 3 torches
For 5 torches
Type
Single
For 3 torches
For 5 torches
AC/DC Feeder. Code
LB.84 at 220/240V
LB.89/98
LB.89/98
Complete: LB.75.C
Only 2A Fuse: LB.76
Complete: LB.75.C
Only 2A Fuse: LB.76
Complete: LB.75.C5
Only 3A Fuse: LB.76V
DC/DC Converter. Code
CV.150
CV.350
CV.350
7
