Appendix

Technical data Stereo Control 035 86
RATING PLATE DATA
Supply voltage:
Absorption in stand-by
Absorption in operation
Operating temperature
AUDIO STEREO FEATURES
RCA input impedance
Input sensitivity
Balancing TYP channels
Balancing MIN channels
Frequency range @ -3 dB
INFRARED SIGNAL FEATURES
Learning capacity
18
18 – 27 Vdc
20 mA (max)
40 mA (max)
5 – 35 °C
14 Kohm
200 mVrms – 1 Vrms
± 0.5 dB
± 1.5 dB
20 Hz – 20 Khz (of the entire transfer,
measured on the amplifier output).
30 Khz – 80 Khz (operation outside this range
is not guaranteed).
