Kenmore ULTRACLEAN 665.1452 Guide D'utilisation Et D'entretien page 13

Removable Top Rack
The removable rack allows you to wash larger items such as stockpots, roasters, and cookie sheets
in the lower level rack.
IMPORTANT: Remove dishes prior to removing the upper rack from the dishwasher.
To remove the rack:
1. To gain access to the track stops, pull the upper rack forward about halfway out of the tub.
2. Press on the edge of the ridged area on the track stop while tipping the track stop toward the
center of the dishwasher. This action releases a small retaining tab that locks the track stop to
NOTE: It is helpful to use 2 hands. Take special note of the orientation of the track stops.
3. With the retaining tab released, pull the track stop straight toward the opposite track to
4. After removing both track stops, gently pull the top rack out of the tracks by rolling
it toward you.
5. Replace the track stops by coming up from under the track and slipping the track stop into
press on the edge of the ridged area while pushing the track stop straight toward the track.
6. Test the track stop by pulling it toward the opposite track to ensure that it is locked in place.
To replace the rack:
1. Gently pull the tracks forward in dishwasher until they stop. Remove track stops. (See steps
1-3 above.)
2. Place the back wheels on each side of the rack into the track and roll the rack into the tracks,
3. Insert front rack wheels on each side of the rack into the track.
4. Slide the rack into the dishwasher.
5. Replace the track stops by coming up from under the track and slipping the track stop into
6. Test the track stop by pulling it toward the opposite track to ensure that it is locked in place.
IMPORTANT: Be sure that the track stops are locked in place and cannot be easily removed. They
keep the rack from coming out of the track.
Track stop - left
Track stop - right
13
