13. Care and Maintenance

Preventive maintenance schedule
If the product, when checked, has faulty/broken parts, do not be use until the faulty parts have been replaced.
Action/Checks
Carry out a general inspection -test the product's
functions. Check that there are no broken or cracked
parts. Check that the product feels stable.
Check that the half-seats can be folded up/down
Check that the rear castors can be rotated and that the
brakes can be applied.
Check that the step is fixed.
Check that the castors are securely fixed to the frame.
Inspect exposed parts for cracks or sharp edges (these
may become unhygienic or injure the care recipient)
Check that there are no loose bolted joints
Repair any damage to the paint to prevent surface
corrosion – this applies particularly to Mover Aqua.
14. Recycling/Disposal
When the product can no longer be used, it should be recycled in accordance with the law/regulations for waste
management in each country. All electrical parts including batteries must be removed and recycled as electrical
components. (Consult your local recycling facility for more information on how the various materials in the product
(metal, plastic, electronics) must be recycled).

15. Technical Specifications

Pos. No. Part Number
1 53-341
2 53-342
3 53-344
4 53-311
5 53-336
6 53-337
7 53-338
8 53-339
9 53-340
10 53-312
11 57-096
12 53-343-L
13 53-343-R
8
Before each use
x
x
x
x
Description
End screw M10, Ø30 mm
Screw, Knee support plate (x4)
Rubber handle, L=92 mm (x2)
Step Aqua
Screw, Seat plate (x3)
Screw, step (x4)
Washer, seat plate (x3)
Locknut, M10
Washer M10
Double castor with no brake Ø75 mm
Double castor with full brake "diameter" 100mm (Aqua)
Bracket, seat plate left
Bracket, seat plate right
Annual overhaul
x
x
x
x
x
x
