Parts List
Ersatzteileliste
Parts List
En
Parts #
Description
6811
O-RING 6X9.5X2MM (BLACK/ 8PCS)
66247
STEERING BALLEND 6.8MM
66791
DECK WING (BLACK)
66796
SHOCK MOUNT SCREW (CW+2/CCW+2)
67187
FRONT SHOCK TOWER (5MM)
67190
LIGHT WEIGHT SPUR GEAR 48 TOOTH
67191
LIGHT WEIGHT 43T SPIRAL BEVEL GEAR
67194
LIGHT WEIGHT MAIN CHASSIS (3MM)
67195
LIGHT WEIGHT STEERING POST (2PCS)
67196
LIGHT WEIGHT WHEEL HEX HUB (2PCS)
67197
LIGHT WEIGHT OUT DRIVES (2PCS)
67198
LIGHT WEIGHT BRAKE CAM (2PCS)
67199
LIGHT WEIGHT BALL (6MM/4PCS)
67200
LIGHT WEIGHT DIFFERENTIAL SHAFT (2PCS)
67201
LIGHT WEIGHT KING PIN BUSHING (4PCS)
67202
LIGHT WEIGHT SHOCK STAND OFF (2PCS)
67203
LIGHT WEIGHT STEERING BUSHING (2PCS)
67204
LIGHT WEIGHT FIXING BALL (4PCS)
67205
LIGHT WEIGHT UPPER SUSPENSION FIXING BALL (4PCS)
67206
LIGHT WEIGHT STEERING PUSH ROD BALL (4PCS)
67207
LIGHT WEIGHT SWAY BAR HOLDER (4PCS)
67210
HIGH MOUNT REAR SHOCK TOWER (112MM)
67211
LIGHT WEIGHT DIFF AXLE SHAFT (2PCS)
67213
LIGHT WEIGHT SHOCK END BALL (4PCS)
67216
ALUMINUM FRONT SPINDLE SET
67217
DCJ CENTER DRIVE SHAFT COMPLETE SET (FRONT/1PC)
67289
BIG BORE SHOCK BODY (16X107MM/2PCS)
67292
SHOCK SHAFT (4X61MM/112MM SHOCK/2PCS)
67296
BIG BORE SHOCK SET (97MM/2PCS)
67298
BIG BORE SHOCK SET (112MM/2PCS)
67344
AIR FILTER BOOT
67345
AIR FILTER SET
67347
AIR FILTER FOAM SET (INNER/OUTER)
67350
SHOCK BOOTS SET
67351
SHOCK END/SHOCK SPRING RETAINER SET
67353
6 HOLES SHOCK PISTON SET (1.2,/1.3/1.4MM)
67356
STONE GUARD SET (RIGHT/LEFT)
67364
FUEL TANK STAND-OFF AND FUEL LINE CLIPS SET
67366
ENGINE MOUNT SET
67368
RADIO TRAY SET
67376
SERVO ARM SET
67378
SERVO HORN SET
67379
PIVOT PLATE (RR/3DEG)
67380
PIVOT PLATE (RF/3DEG)
67381
REAR SUSPENSION ARM SET
67382
REAR CHASSIS STIFFENER MOUNT
67383
REAR CHASSIS STIFFENER
67384
FRONT SUSPENSION BLOCK (FR)
67385
FRONT SUSPENSION ARM SET
67386
FRONT HUB CARRIER SET (RIGHT/LEFT/10DEG)
67391
FRONT SUSPENSION BLOCK (FF)
67394
SERVO SAVER CRANK SET
67397
STEERING CRANK SET
67398
STEERING PLATE
67400
STEERING BRACE
67401
FRONT CHASSIS STIFFENER
67402
AXLE (1PC)
67404
UNIVERSAL JOINT REBUILD KIT
67405
DRIVE SHAFT (91MM)
67406
CENTER DRIVE SHAFT COUPLING
67408
CENTER DRIVE SHAFT (105MM)
67411
BODY MOUNT SET
67415
SUSPENSION SHAFT 4X71MM SILVER (FRONT/INNER)
67417
SUSPENSION SHAFT (REAR/INNER)
67419
DIFFERENTIAL MOUNT (2PCS)
67420
CENTER DIFF MOUNT COVER
67421
BRAKE DISK ROTOR (2PCS)
67422
AIR FILTER BRACE
67424
FUEL TANK COUPLER AND NUT
67426
FUEL FILTER
67433
BIG BORE SHOCK CAP
67435
BIG BORE SHOCK BODY (16X97MM/2PCS)
67436
SHOCK SHAFT (4X51MM/2PCS)
67438
BALL BEARING 8X14X4MM (2PCS)
67439
BALL BEARING 5X11X4MM (2PCS)
67440
CLUTCH BELL 16 TOOTH
67444
HB D8 BODY (CLEAR)
67447
BIG BORE SHOCK SPRING (WHITE/60MM/81GF/2PCS)
67451
BIG BORE SHOCK SPRING (YELLOW/68MM/68GF/2PCS)
67464
STEERING TURNBUCKLE 4X55MM (2PCS)
67468
EXHAUST HANGER WIRE
67470
WASHER 5X8X0.5MM (6PCS)
67473
BRAKE WIRE (2PCS)
67491
STEERING LINKAGE SET
67492
17MM WHEEL NUT (BLACK/4PCS)
67499
SPIRAL PINION GEAR 10 TOOTH
67510
SWAY BAR (2.8MM)
67511
SWAY BAR (2.4MM)
67514
SPACER 3X8.5X3MM (6PCS)
67515
BIG BORE SHOCK MAINTENANCE SET
67516
BALL END SET
Liste de pièces
パーツリスト
Parts #
Description
67518
UNIVERSAL DRIVE SHAFT SET
67520
THROTTLE LINKAGE SET
67521
WING MOUNT SET
67523
FUEL LINE SET
67524
FUEL TANK SET
67525
FLYWHEEL (3PINS/BLACK)
67527
HB DISH WHEELS (WHITE/4PCS)
67528
BIG BORE SHOCK SPRING ADJUST NUT (BLACK/2PCS)
67529
BIG BORE SHOCK BOTTOM CAP (BLACK/2PCS)
67530
HB D8 BODY/WING DECAL
67531
CNC EXHAUST PIPE MOUNT (BLACK)
67534
BALL 5.8X5.6MM (4PCS)
67625
DIFF MOUNT SPACERS (2PCS)
68182
ENGINE MOUNT SET (7MM/2PCS)
68184
SUSPENSION SHAFT (OUTER/THREADED)
68185
AH ALUMINUM REAR HUB
68186
HD FUEL TUBE
68187
SPACER 3X8.5X5MM
86598
WASHER 13X16X0.2MM (10PCS)
94388
CAP HEAD SCREW M3X16MM (10PCS)
94505
CAP HEAD SCREW M4X12MM (10PCS)
94531
FLAT HEAD SCREW M4X15MM (HEX SOCKET/10PCS)
94554
BUTTON HEAD SCREW M4X10MM (HEX SOCKET/10PCS)
94675
CAP HEAD SCREW M3.5X14MM (8PCS)
94676
CAP HEAD SCREW M3.5X18MM (8PCS)
94677
CAP HEAD SCREW M3.5X42MM (8PCS)
100550
PAN HEAD SCREW M5X8MM (HEX SOCKET/10PCS)
100551
LOCK NUT M2.5 (4PCS)
100553
WASHER M2.9X8X0.5MM (8PCS)
100554
SET SCREW M3X14MM (4PCS)
100555
SET SCREW M4X3MM (4PCS)
100556
FLAT HEAD SCREW M3X14MM (HEX SOCKET/10PCS)
100557
FLAT HEAD SCREW M3X16MM (HEX SOCKET/10PCS)
100558
BUTTON HEAD SCREW M3X4MM (HEX SOCKET/10PCS)
100559
BUTTON HEAD SCREW M3X14MM (HEX SOCKET/10PCS)
100560
BUTTON HEAD SCREW M3X16MM (HEX SOCKET/10PCS)
HB70545
BODY CLIP, MED. 6MM (E-ZILLA 10)
HBC8003
FRONT BUMPER (LIGHTNING SERIES)
HBC8009-1
DIFFERENTIAL CASE (LIGHTNING SERIES)
HBC8017
REAR UPPER TURNBUCKLE 5X51MM (LIGHTNING SERIES)
HBC8018-1
FRONT UPPER TURNBUCKLE 5X30MM (LIGHTNING SERIES)
HBC8019
DIFFERENTIAL HOUSING (LIGHTNING SERIES)
HBC8020-1
RUBBER SEALED BEARING 8X16MM (4PCS) (LIGHTNING SERIES)
HBC8021
DIFFERENTIAL PADS (LIGHTNING SERIES)
HBC8022
DIFFERENTIAL SHAFT (LIGHTNING SERIES)
HBC8043
3PCS RACING CLUTCH SHOE (LIGHTNING SERIES)
HBC8045
CLUTCH SPRINGS FOR C8043, C8043-1 (LIGHTNING SERIES)
HBC8048
DISK BRAKE PLATE (LIGHTNING SERIES)
HBC8050
3X14MM SCREWS (4PCS/LIGHTNING SERIES)
HBC8058-1
SW. DUST-PROOF COVER BLACK (LIGHTNING SERIES)
HBC8059
CENTER GEAR HOUSING (LIGHTNING SERIES)
HBC8086
ANTENNA (LIGHTNING SERIES)
HBC8088
6X10MM SEALED BEARING (LIGHTNING SERIES)
HBC8090
WHEEL ANGLE ADJUSTER (LIGHTNING SERIES)
HBC8096
3X17MM SHAFT (LIGHTNING SERIES)
HBC8100
6.8MM BALL END (L/LIGHTNING SERIES)
HBC8101-1
HARD STEEL DIFFERENTIAL GEAR SET (LIGHTNING SERIES)
HBC8108
FRONT STABILIZER SET (LIGHTNING SERIES)
HBC8113
BODY CLIP (LIGHTNING SERIES)
HBC8122-4
SHOCK OIL #3000
HBC8122-6
SHOCK OIL #7000
HBC8122-9
SHOCK OIL #500
Z082
FLAT HEAD SCREW M3X8MM (HEX SOCKET/10PCS)
Z083
FLAT HEAD SCREW M3X10MM (HEX SOCKET/10PCS)
Z084
FLAT HEAD SCREW M3X12MM (HEX SOCKET/10PCS)
Z086
FLAT HEAD SCREW M3X18MM (HEX SOCKET/10PCS)
Z087
FLAT HEAD SCREW M3X20MM (HEX SOCKET/10PCS)
Z216
BUTTON HEAD SCREW M3X15MM (HEX SOCKET/4PCS)
Z224
WASHER M3X8MM (10PCS)
Z242
E CLIP E2MM (20PCS)
Z307
FLAT HEAD SCREW M4X10MM (HEX SOCKET/THIN TYPE/4PCS)
Z351
BUTTON HEAD HEX SOCKET SCREW M3X6MM
Z352
BUTTON HEAD SCREW M3X8MM (HEX SOCKET/10PCS)
Z353
BUTTON HEAD SCREW M3X10MM (HEX SOCKET/10PCS)
Z354
BUTTON HEAD SCREW M3X12MM (HEX SOCKET/10PCS)
Z357
BUTTON HEAD SCREW M3X20MM (HEX SOCKET/10PCS)
Z492
TP. BINDER HEAD SCREW M2.2X4.8MM (8PCS)
Z542
CAP HEAD SCREW M3X8MM (12PCS)
Z544
CAP HEAD SCREW M3X12MM (6PCS)
Z547
CAP HEAD SCREW M3X20MM (6PCS)
Z548
CAP HEAD SCREW M3X22MM (12PCS)
Z653
NUT M3 (6PCS)
Z663
LOCK NUT M3 (6PCS)
Z664
LOCK NUT M4 (4PCS)
Z700
SET SCREW M3X3MM (6PCS)
Z702
SET SCREW M3X5MM
Z704
SET SCREW M3X8MM
Z721
SET SCREW M4X4MM (4PCS)
Z725
SET SCREW M4X10MM
Z740
SET SCREW M5X4MM BLACK
Z800
SPRING WASHER 3X6MM (20PCS)
