Audio Pro LV-SUB FLAT Manuel D'utilisation page 5

HOW TO CHANGE HOUSE CODE ON THE LV-SUB
*
HOW TO CHANGE ZONES FOR THE LV-SUB
*
8
PUSH SHORT TO TOGGLE BETWEEN HOUSE CODE 1, 2
OR 3 (ALSO SHOWN ON FRONT DISPLAY)
The House Code selector is located on the rear panel
of the LV-SUB FLAT. Set the same number (1, 2 or 3) as
on the TX100/TXD200 transmitter. The House Code can
be likened to a channel via which wireless signals are
transmitted.
Within the network, music can be sent simultaneously from
3 different audio sources.
PUSH SHORT TO TOGGLE BETWEEN ZONES A, B OR C
(ALSO SHOWN ON FRONT DISPLAY).
The Zone selector is located on the rear panel of the LV-SUB
FLAT. Set the same letter (A, B or C) as the other loudspeakers
you wish to have in the same zone.
A House Code (channel) can be divided up into a total of 3
zones. You can control the volume level of these zones indi-
vidually using the remote control. You can, for example, have
one volume level in the kitchen, another in the living room,
and a third in the bedroom.
USE MULTIPLE TRANSMITTERS AND SPEAKERS
SIMULTANEOUSLY WITH THE HOUSE CODE 1, 2 OR 3
Transmitter: House Code 3
Speakers: House Code 3
By using the House Codes (channels) you can share the wireless network for up to two separate
networks. Then you can simultaneously play music from various audio sources (from two different
transmitters) to different pairs of LIVING speakers.
ADJUST VOLUME SEPARATELY IN THREE DIFFERENT ZONES
In order to be able to have the same music at different volumes in different rooms/areas, you can di-
vide each House Code into 3 different volume zones. Each zone can have a different volume. This is
very handy if, for example, you want to have one volume level in the living room and a lower volume
in the kitchen. You can have as many LIVING speakers in each zone as you want, or just one pair.
The zone volume is easily controlled with the remote unit.
HOUSE CODE 1
Speaker and transmitter set to
same House Code (channel).
Zone A
2 9 0 8
Zone volume
Living LV2e + LV-SUB FLAT Living LV1 + LV-SUB FLAT
Note:
1. All LV speakers are default Zone A, and volume level 17.
2. Each House Code (1, 2 and 3) can be split into up to 3 zones (A, B and C).
3. You can have as many speakers you like on each House Code, and as many as you want in each zone.
A zone does not have to be one room, can be whole floor in house.
Transmitter: House Code 3
Speakers: House Code 3
Zone B Zone C
1 5
Zone volume Zone volume
Living LV1 + LV2e + LV33
9
