PAIRING WITH TXD200/LV-HUB TRANSMITTERS
The feature to pair LV-SUB flat only works with the TXD200 and LV-HUB
transmitter, and in combination with newer Living speakers with pairing
functionality.
LV-SUB FLAT also works with standard TX100 transmitter.
By pairing, you lock your Audio Pro network from other peoples Audio
Pro Wireless networks. In unpaired mode, the TXD200 and LV33 will work
with all Audio Pro Wireless products.
PAIR YOUR LV-SUB FLAT WITH TXD200/LV-HUB TRANSMITTER
1. Press Pairing button on transmitter for 2 seconds. LED starts to flash
Green.
2. Press and hold ZONE/PAIR button on LV-SUB FLAT for 3 seconds.
(Button is located on rear amplifier panel). LED starts to flash Green, and
display shows: Pr -
3. When LEDs on both transmitter and subwoofer goes to steady green,
the subwoofer is paired to your system.
Note:
1. Pairing will not work with older Living speakers.
2. To unpair system (all speakers in same volume zone will be unpaired):
- Disconnect TXD200/LV-HUB from power.
- While pressing the pairing button, reconnect TXD200 to power, and hold pairing button for
6 seconds. The units will now be unpaired.
WALLMOUNTING
Drill guide:
346mm
Prepare the included wallmounts first and attach to LV-SUB with enclosed screws suitable. Secure
suitable screws in your wall according to drill guide. Use screw suitable for your wall material
(screws not included) and the weigth of LV-SUB FLAT. Hang the subwoofer on to the screws secured
in the wall. Keep lower rubber feet on, as they are used as distances to your wall.
6
ANALOGUE CONNECTION TO STEREO/RECEIVER
You can make standard connection from the LV-SUB FLAT to any stereo/receiver equipped with a
sub-output. Connect with a cable from the sub-output to the Line In on the rear of the LV-SUB.
MAKE SURE: that you have switched input selector to WIRED.
ADD MORE LV-SUBS FLAT TO YOUR WIRELESS NETWORK
You can add an unlimited number of LV-SUB FLAT subwoofers to the network, as long as they are
positioned within the transmitter's range
All the LV-SUB FLAT will receive signal from transmitter using the same House Code.
You can have multiple subwoofers in one room or individual subwoofers in several rooms.
PLACEMENT OF THE SUBWOOFER
Since the LV-SUB FLAT functions wirelessly, its placement is simple. Just connect it to the power
socket and place it within range of the transmitter.
For optimal bass reproduction, the subwoofer should be placed close to a wall or in a corner.
Corner placement can result in a powerful bass, so try different places until you are satisfied with
the bass reproduction.
+
