EXTENSION CORDS

Grounded tools require a three wire extension
cord. Double insulated tools can use either a two
or three wire extension cord. As the distance from
the supply outlet increases, you must use a heavier
gauge extension cord. Using extension cords with
inadequately sized wire causes a serious drop in
voltage, resulting in loss of power and possible tool
damage. Refer to the table shown to determine the
required minimum wire size.
The smaller the gauge number of the wire, the greater
the capacity of the cord. For example, a 14 gauge
cord can carry a higher current than a 16 gauge cord.
When using more than one extension cord to make
up the total length, be sure each cord contains at
least the minimum wire size required. If you are using
one extension cord for more than one tool, add the
nameplate amperes and use the sum to determine
the required minimum wire size.
Guidelines for Using Extension Cords
• If you are using an extension cord outdoors, be sure
it is marked with the suffix "W" to indicate that it is
acceptable for outdoor use.
• Be sure your extension cord is properly wired and in
good electrical condition. Always replace a damaged
extension cord or have it repaired by a qualified
person before using it.
• Protect your extension cords from sharp objects,
excessive heat and damp or wet areas.
• When stringing lights together, consider the total
Amperes draw when selecting the extension cords.
Recommended Minimum Wire Gauge
For Extension Cords*
Nameplate
Amperes
0 - 2.0
2.1 - 3.4
3.5 - 5.0
5.1 - 7.0
7.1 - 12.0
12.1 - 16.0
16.1 - 20.0
* Based on limiting the line voltage drop to five volts at 150%
of the rated amperes.
READ AND SAVE ALL INSTRUCTIONS
FOR FUTURE USE.
Extension Cord Length
25' 50' 75' 100'
18 18 18 18
18 18 18 16
18 18 16 14
18 16 14 12
16 14 12 10
14 12 10 --
12 10 -- --
WARNING
cific charging instructions, read the operator's
manual supplied with your charger and battery.
Inserting/Removing the Battery
Insert the battery pack by sliding battery pack into
the body of the tool. Insert the battery pack until the
battery latches lock.
To remove the battery pack, press in both battery
latches and slide the battery pack off of the tool.
Inserting/Removing Extension Cords
When not using the AC option, make sure the AC
doors are closed completely.
To operate the light on AC Power, open the
and plug in a suitable extension cord into the light.
When running the light on AC Power, an extension
cord can be run from the light. Open the
plug in a suitable extension cord.
NOTE: Do not exceed 11A of output. Reduce AC
Output Amps by 1A per additional light added in
sequence.
To learn more about the ONE-KEY functionality for
this tool, please reference the Quick Start guide in-
cluded with this product or go to milwaukeetool.com/
One-Key. To download the ONE-KEY app, visit the
App Store or Google Play from your smart device.
WARNING
light is on.
150'
1. Insert battery pack or plug into AC power.
2. Press the Power
16
3. Press the Brightness
14
High (4400 lumens), Medium (2100 lumens), and
12
12 Low (1000 lumens). The light will default to the
--
selected brightness the next time it is turned on.
--
4. Press the Area Selector
--
back, or full lighting. The light will default to the
selected area the next time it is turned on.
5. Press the Power
NOTE: On battery power, the light will flash to indi-
cate the battery is reaching end-of-charge.
The light can be oriented in multiple ways:
• Placing it on its base
• Hanging it upright by the handle
• Hanging it upside down by the rafter hook
4
ASSEMBLY
Recharge only with the charger
specified for the battery. For spe-
ONE-KEY™
OPERATION
To reduce the risk of injury, do not
look directly into the light when the
Using the Light
button to turn on the light.
button to cycle through
button to select front,
button to turn the light off.
Orientation
door
door and
