FIELD TEST DEVICE - LoRaWAN Europe - User Guide V1.2.0
Range
S250
S251
S252
GB
S53
S254
S255
S256
S257
S260
S261
S280
S281
S201: SF value
The range allows you to set a "Spreading Factor" (SF) value to use when the device has not been configured to "Adaptive Data Rate" (ADR).
This value will then be used to transmit the frame on the LoRaWAN network. When the ADR is active, the SF will automatically be managed
by the network.
S214 and S215: LORA APP_EUI
The S214 and S215 ranges determine the APP_EUI key used during the JOIN phase in OTAA mode. The key is made up of 16 characters
spread across these 2 ranges, which can each contain 8 characters. The S214 range contains the start of the key, while the S215 range
contains the end of the key.
Example : 0018B244 41524632
S214 = 0018B244
S215 = 41524632
Content
Configuration Channel 0
Configuration Channel 1
Configuration Channel 2
Configuration Channel 3
Configuration Channel 4
Configuration Channel 5
Configuration Channel 6
Configuration RX2
RESERVE
RESERVE
NETWORK ID
DEVICE ADDRESS
Default value
1
Mandatory operational channel LoRaWAN
1
Do not change this value
1
0
0
0 : Channel desactivated
Other : User configuration
0
0
0: Channel deactivated
1 1: LoRaWAN default configuration
Other: User configuration
2200 Read-only
3600 Read-only
0 Read-only
Comments
