7. Remote control

Activate the MoveControl by double-
clicking the I/O button on the remote con-
trol - the LED is ON.
Now you can execute the movements
according to the symbols shown on the
remote control. The vehicle only moves
as long as you keep the buttons pushed
down.
The integrated "Soft-Start" gives an acoustic sig-
nal when starting to move which is meant as a
warning signal of a caravan or trailer starting to
move.
The movement buttons have to be pressed re-
spectively one by one. The arrows by the buttons
show the respective direction of motion.
Forward
Curve drive:
Left wheel
forward
Left wheel
backward
Rotation
(pushing 2 buttons simultaneously) :
+
Clockwise rotation
+
Anti clockwise rotation
Turn off the MoveControl by pushing the
I/O button once at the remote control. The
red LED will turn OFF.
Backward
Right wheel
forward
Right wheel
backward
If the movements do not correspond to the sym-
bols on the remote control, the cable connections
of the right and the left drive units need to be
checked and - if necessary - exchanged (see
wiring diagram ).
It is important that in such a case you turn the
isolating switch off and disconnect the electronic
box from the electricity supply.
Make sure that you never exchange
the Positive (+) and Negative (-) of
the electricity supply.
If you experience radio interference you can con-
nect the cable the cable between handset and the
E-Box.
The cable also can be used if the battery of the
remote control is used up.

Security advice:

Be carefull that no one is in the mov-
ing area while mamoeuvring the
caravan!
Also check on the side of the cara-
van which turned away from you.
Keep a safe distance during moving.
Always keep sufficient distance of
the friction rollers after maintenance
or cleaning.
Switching plant absolutely current-
freely and
against roll away at works in the
area of the friction rollers.
E-Box
safeguarding vehicle
