20 EN

FUNCTIONAL DESCRIPTION

Limetree
on
1
1. The toggle switch on the front of the network player has three
functions:
a) Push it up briefly to turn the unit on. A second short push will
turn the unit off again.
b) To change into DSD mode, press and hold the switch in the
upper position for three seconds.
c) For a hardware reset hold the toggle switch for ten seconds in
the upper position. The Power indicator will start flashing rapidly,
and the device will reboot with the default settings.
Network
SR DSD
2 3 4
Note: after turn-on the device will need some time to
boot. The unit is ready for use when the Sample Rate
LED is lit. After turn-off the Power LED will flash until
the unit has shut down.
2. Function indicator of the input signal sampling rate.
The color of this LED will change along with input
signal sampling rate.
Green PCM 44.1/48 kHz
Cyan PCM 88.2/96 kHz
Blue PCM 176.4/192 kHz
White PCM 352.8/384 kHz
Yellow DSD 64
Orange DSD 128
Purple DSD 256
3. Function indicator for the DSD mode: when the LED is
lit yellow, the device is in the DSD mode. When the LED
is dark, the device is in the "bit-perfect" mode.
4. Headphone socket 3.5 mm. Plugging in the headphone
will activate the headphone output and the line output
is muted.

