Troubleshooting
Green Yellow
Lights Light
Top light Off
on
Top light Off
on
Off Off

Reset

If a fault causes a RED error light to illuminate or flash and the fault condition is corrected, you use
RESET the Wall Connector to resume normal operation. There are two ways to REST the Wall
Connector:
• Press the RESET button for two to three seconds until the top lights changes from RED to
GREEN. This clears the fault message but does not reboot the Wall Connector.
• In a rare situation, you might need to force the Wall Connector to reboot without recycling the
input power. Hold the RESET button for five seconds. When the top light changes from RED
to GREEN, release the RESET button. The top light should continue to illuminate GREEN. If the
light returns to flashing RED, the fault state has not been corrected.
24
Red Light Auto-Retry
5 flashes Not
Applicable
6 flashes Not
Applicable
Solid red No
What it Means What to Do
Circuit Breaker Move one or more
Sharing Network: Wall Connectors to a
More than three different circuit and
Wall Connectors are disconnect it from this
set to Slave. Circuit Breaker
Sharing Network.
Circuit Breaker Contact Tesla.
Sharing Network:
The networked Wall
Connectors have
different maximum
current capabilities.
Wall Connector Contact Tesla.
hardware failure.
Possible failures
include the
following:
• Contactor
failed.
• Self test failed.
• Other possible
hardware
failures.
