2. Mark center of mounting hole location, using slots in
bracket as a template.
3. Remove bracket. Drill 1/8" mounting hole.
4. Mount to unit using (1) 1/4‑20 x 3/4" button head
screw 3 , and (1) 1/4‑20 serrated flange nut
5. Tighten the screws with 5/32" hex key.
6. Wrench tighten all screws securely. Do not over tighten.

WARNING: Cabinet MUST be attached to a stud in a
wood frame wall. Failure to do so may cause personal
injury or product damage.
Wood frame wall, concrete or other surfaces require
hardware for mounting. Use appropriate hardware per your
local building codes. Failure to do so may cause personal
injury or product damage.
7. Align cabinet with a stud. Adjust leveler feet
8. Drill 1/8" pilot hole.
9. Attach cabinet to stud using appropriate screw
10. Please refer to Leveling Foot Adjustment under the
Operation section.
Shelf Placement (Fig. E)
items needed
• 1/4‑20 x 3/4" Button Head Screw (Qty: 8)
• 5/32 Hex Key
Process
1. Insert the shelf from the front of the unit.
2. Place in desired mounting location in the back of the
unit, and rotate into place.
3. Attach using (2) 1/4‑20 x 3/4" button head screw
as shown.
4. Repeat untill all (4) shelves are in place.
5. The second shelf from the top should be placed in the
fifth hole from the top for proper lock positon.
6. Tighten the screws with 5/32" hex key.
7. Wrench tighten all screws securely. Do not over tighten.
Wall Cabinet
Shelf Attachment (Fig. F)
items needed
• 1/4‑20 x 3/4" Button Head Screw (Qty: 4)
• 1/4‑20 Serrated Flange Nut (Qty: 4)
• 5/32 Hex Key
• 7/16" Socket
• Socket Wrench
Process
1. Place cabinet in its upright position.
2. Insert shelf from front of the unit.
3. Place the side of the shelf in the desired moutning
location in the side of the unit and rotate into position
as shown.
4. Attach using (4) screws, (4) nuts in mounting holes
as shown.
5. Tighten the screws with 5/32" hex key.
6. Wrench tighten all screws securely. Do not over tighten.
Option 1- Mounting Cabinet (Fig. G)
nOTE: Option 1 is for hanging cabinet to Trackwall only.If
hanging cabinet directly on the wall, go to Option 2.
Process
4 .
1. Attach top and wall bracket as shown using (4) screw
and (4) nuts.
2. Tighten the screws with 5/32" hex key and socket
wrench. Do not over tighten.
3. Attach the wall cabinet to the Trackwall.
Option 2- Mounting Cabinet (Fig. H)

1 if needed.

8 .

items needed
Mounting hardware as defined by your local building code.
Process
1. Align wall cabinet with studs.
2. Mark and drill (2) 1/8" pilot holes.
nOTE: Use outside holes for mounting to studs on
24" centers.
9
3. Use inside set of holes for mounting to studs on
16" centers.
4. Attach wall cabinet to studs using appropriate hardware
as defined by your local building code.
Grommet Assembly (Fig. I)
items needed
• Grommet (Qty: 3)
Process
1. Place the grommet
Base Cabinet
Assembly (Fig. J)
Items Needed
• Filler Bracket (Qty: 1)
nOTE: Filler bracket
work surface and top of the base cabinet. If you chose not to
use a worksurface the filler strip is not required.
Process
1. Install the leveling feet. Please refer to Assembling the
Leveling Feet under the Assembly section.
2. Position filler bracket flush to the top front edge of the
base cabinet, inside the weld tabs.
3. Attach filler bracket with adhesive tape.
4. Please refer to Leveling Foot Adjustment under the
Operation section.
WARNING: Wall cabinet MUST be attached to two
studs in a wood frame wall. Failure to do so may cause
personal injury or product damage. Use appropriate
hardware per your local building codes. Failure to do so
may cause personal injury or product damage.
WARNING: Use two or more people to move and
assemble cabinet. Failure to do so may cause personal
injury or product damage.
WARNING: Cabinet must be mounted level. Failure to
do so may cause personal injury or product damage.
10 in the hole.
11 is used to fill the gap between the
