GENERAL INFORMATION

The CB 516/24V switch-mode battery charger has been expressly designed for the
caravanning and boating sector and can automatically charge 24Vd.c. lead batteries.
The battery charger is protected against overtemperature and the 24Vd.c. outputs are
protected against short circuit and polarity inversion.
The charging system is carried out in 4 stages:
1) Battery charging
Note: the end-charge voltage is reached only if the battery is efficient.
2) W hen the
minutes (lead batteries) or 8 hours (gel batteries) with constant voltage.
3) Constant
4) After 10 hours, the battery charger reaches the
again only when the battery voltage is lower than 26Vd.c.
The high frequency switching technology allows to have high performances with small
dimensions and limited weight.
CONNECTIONS
GB
6
with maximum current until the end-charge voltage is reached:
end-charge threshold is reached the charger continues to operate for 90
voltage holding 27.6Vd.c.(gel batteries) or 27.0Vd.c. (lead batteries)
Battery
Pb / Gel
Fuse 24Vd.c.
F1 - F 15A
BLACK
24Vd.c. BATTERY
- Technical data are indicated also in the label inside the cover -
stand-by
1) + 24Vd.c. supply (BLEU)
2) - 24Vd.c. supply (BLACK)
mode and begins to operate
230Va.c. On/Off
Fuse 230Va.c.
F2 - F 2A
