Thank you very much for choosing our product. For safety purpose, please read this manual carefully before your
operation. This manual included installation and using information. Please install and operate it according to this manual.
Part 1 Product

1.1 Product introduction

This product is designed for indoor use. Suitable applications include wash or effect lighting for architectural, stage or
nightclub applications. This product can also be installed for use in signage and advertising using the dynamic functions
available with DMX512 control. Direct input of DMX512 signal allows the units to be controlled from any DMX512
controller. This product can be operated as a single unit or in multiple units for large applications.

1.2 Technical Specifications

Voltage: AC100-240V, 50/60Hz
Power: 200W
Light Source: 18X10W RGBW 4in1 ultra bright LED
Lifespan: around 50,000-100,000 hours
Control: DMX 512, 4/8 channels
Control mode: DMX 512, Auto mode, Master/Slave, Sound active
Beam angle: 25 º
Product Size: 328*268*286mm
Net Weight：7Kg

1.3 Safety Warning

IMPORTANT:
ALWAYS READ THE USER MANUAL BEFORE OPERATION. PLEASE CONFIRM THAT THE POWER SUPPLY
STATED ON THE PRODUCT IS THE SAME AS THE MAINS POWER SUPPLY IN YOUR AREA.
● This product must be installed by a qualified professional.
● Always operate the equipment as described in the user manual.
● A minimum distance of 0.5m must be maintained between the equipment and combustible surface.
● The product must always be placed in a well ventilated area.
● Always make sure that the equipment is installed securely.
● DO NOT stand close to the equipment and stare directly into the LED light source.
● Always disconnect the power supply before attempting and maintenance.
● Always make sure that the supporting structure is solid and can support the combined weight of the products.
● The earth wire must always be connected to the ground.
● Do not touch the power cables if your hands are wet.
ATTENTION:
● This product left the place of manufacture in perfect condition. In order to maintain this condition and for safe operation,
the user must always follow the instructions and safety warnings described in this user manual.
● Avoid shaking or strong impacts to any part of the equipment.
● Make sure that all parts of the equipment are kept clean and free of dust.
● Always make sure that the power connections are connected correct and secure.
● If there is any malfunction of the equipment, contact your distributor immediately.
● When transferring the product, it is advisable to use the original packaging in which the product left the factory.
● Shields, lenses or ultraviolet screens shall be changed if they have become damaged to such an extent that their
effectiveness is impaired.
● The lamp (LED) shall be changed if it has become damaged or thermally deformed.
PART 2 INSTALLATION
2.1 Mounting:
2.1-1 Hanging
The product can be mounted in a hanging position using the supporting bracket. The bracket should be secured to the
mounting truss or structure using a standard mounting clamp. Please note that when hanging the unit a safety cable
should also be used
.
2.1-2 Upright
The product can be mounted in an upright or sitting position using the supporting brackets.
