6 | English

TECHNICAL DATA

Article number
Model -BL 20V PRO
Drill Capacities:
Wood
Mild Steel
Masonry
Maximum Torque
Revolutions Per
Minute (no load)
Impact Rate
Chuck Capacity
Weight (drill &
battery)
Sound emission values determined according to
EN 60745-1
Typically the A-weighted noise levels of the product are:
Sound pressure
level
Sound power
level
Uncertainty K
Vibration total values a
and uncertainty K determined according to EN
60745-1
Vibration level max:
a
h
K
Battery:
Type
Voltage
Rating
Charging time
(80%)
Charging time
(100%)
Charger:
Rated Voltage
Rated Frequency
Rated D.C. Out-
put Voltage
Rated D.C. Out-
put Current
41316
CDD
mm 35
mm 13
mm -
Nm 55
0-500
min
-1
0-1.700 0-1.700
0-7.500
i/min -
0-25.500
mm 13
kg 1,5
dB(A) 77,5
dB(A) 88,5
dB 3
(triax vector sum)
h
m/s 2,04
2
m/s 1,5
2
Li-Ion
V 20
Ah 2,5
min 56
min 66
V 100-240
Hz 50/60
V DC 22
A 3,0
IDENTIFICATION
1. Variable speed trigger switch
41317
2. Forward/reverse switch
3. Keyless chuck
CHD
4a. Torque setting ring
4b. Hammer Rotary selector
5. Two speed selector
35
6. LED working light
7. Belt Clip
13
8. Battery pack release button
13
9. Battery pack
10. Battery Charger
55

BEFORE OPERATION

0-500
FITTING AND REMOVING THE BATTERY
Slide the battery into the handle until it engages. To
remove the battery, push the yellow battery release
button and pull the battery out of the handle.
13
CHECKING THE BATTERY STATUS (11)
1,6
The battery is equipped with a charge level indicator.
Use the battery charge status indicator to plan your
work and/or to avoid deep discharge.
To check the charge level, press the battery charge
ƒ
level indicator button.
The charge level is represented by red,yellow and
ƒ
green LEDs.
85,5
When the battery is fully charged all three LEDs light up.
ƒ
LED battery status
96,5
indicator
Green LED on
3
Yellow LED on
Red LED on
CHARGING THE BATTERY
:
NOTE Before first using your cordless drill, please
11,72
charge the battery first.
The charger is equipped with a LED charging indicator
1,5
lamp. During charging, the indicator light will light up
red. After completion of charging,the light turns green.
Connect the charger to a suitable mains socket. The
ƒ
green charging light comes on
Slide the battery onto the charger, the red charging
ƒ
light comes on
The charger may become warm and buzz slightly during
ƒ
charging. This is normal and does not indicate a fault.
OPERATION INSTRUCTIONS
FITTING TOOLS
Both drill bits and screwdriver bits can be fitted to
the chuck.
To open the chuck rotate the chuck (3) anti-clock-
ƒ
wise
Insert your tool and tighten the chuck by hand
ƒ
CHANGING SPEED (5)
To prevent the risk of damage to gears change
speeds only when the machine has come to a
complete stop.
The two speed selector controls the speed of the drill.
Capacity
>100%
>67%
>30%
