Parts List Rotary Hammer RDP-HD60
NO
ENGLISH DESCRIPTION
1
Protection sleeve assy
1-1
Protective cap
1-2
washer
1-3
Snap ring
1-4
Reraining ring
1-5
Snap ring
1-6
Protection sleeve
1-7
Thrust ring
1-8
Ball φ7.14
1-9
Holding plate
1-10
Pagoda spring
2
Gear housing assy
2-1
Retaining ring
2-2
Oil Seal 31*40*7
2-3
Gear housing
2-4
HK0709 needle bearing
2-5
Tab Washer
2-6
Screw ST4.2*13
3
Selector knob Assy
3-1
O-ring
3-2
pin
3-3
Selector knob
3-4
Compression spring
3-5
Red button
4
Screw ST4.8*55
5
Ratchet sleeve assy
5-1
O-ring
5-2
Thrust ring
5-3
Compression spring
5-4
40teeth Big gear
5-5
Ratchet sleeve
5-6
Straight Pin
5-7
Catch disk
5-8
Oil Seal 16*5*9.5
5-9
spacing collar
5-10
Impact bolt
5-11
Guide bushing
5-12
O-ring
5-13
O-ring
5-14
Damping bushing
5-15
O-ring
6
Piston assy
6-1
Striker
6-2
O-ring
6-3
Piston
6-4
Piston pin
6-5
U-shaped gasket
7
Intermediate flange assy
7-1
Bushing
7-2
pin
7-3
Intermediate flange
7-4
Oil core
7-5
O-ring
7-6
Ball bearing 609
7-7
End shield
7-8
Screw ST4*10
NO
ENGLISH DESCRIPTION
8
Cylindrical gear assy
8-1
Ball bearing 607
8-2
Cylindrical gear
9
Compression spring
10
Clutch
Wobble bearing and
11
HK0912 needle bearing
11-1
Wobble bearing
11-2
HK0912 needle bearing
12
End shield
13
Screw ST5*14
14
Toothed shaft Assy
14-1
Ball bearing 699
14-2
Toothed shaft
15
Shift fork
16
Spring clip
17
O-ring
18
bearing shim
19
Rotor
20
Ball bearing 607
21
Rubber sleeve
22
Air-deflector ring
23
Screw ST3.9*16
24
Stator
25
Pin
26
Motor barrel
27
Shock-absorbing sleeve
28
Spring
29
sleeve
30
Motor housing
31
Washer φ4
32
Brush holder base
33
Screw ST3.5*12
34
Upper brush holder Assy
34-1
Upper brush holder
34-2
Copper brush holder
34-3
Carbon brush
34-4
Coil Spring
35
Switch button
36
Housing cover
37
Screw ST3.9*30
38
Screw ST4.2*18
39
Cord clip
40
Inductance
41
Switch Assy
41-1
Switch
41-2
Cable
41-3
Cord guard
42
Auxiliary handle Assy
42-1
Clamping band
42-2
T-bolt
42-3
Clamp holder
42-4
Clamp
42-5
Compression spring
42-6
Auxiliary handle
43
Depth Guage
