6
| English
TECHNICAL DATA
Article number
Model
Rated voltage
Power
No-load speed
Pad Size
Weight
Sound emission values determined according to
EN 60745-1
Typically the A-weighted noise levels of the product are:
Sound pressure level
Sound power level
Uncertainty K
Vibration total values a
and uncertainty K determined according to EN
60745-1
Vibration level max:
a
h
K
IDENTIFICATION
1. Trigger switch
2. Lock-on button
3. Oscillation speed selector
4. Rear Handle
5. Paper Clamp
6. Hook & loop sanding base
7. Front Handle
8. Dust Box
OPERATION INSTRUCTIONS
WARNING: To avoid injury from accidental startups,
f
remove the plug from the power source outlet be-
fore making any adjustments.
Do not use excess pressure while sanding and always
f
sand in same direction as the grain of the wood. Let
the sandpaper do the work. Apply even pressure
over the entire workpiece.
Check the wear on the sandpaper at regular intervals
f
and replace as necessary.
NOTE: Always turn the switch OFF and unplug
the sander before changing sheets of sandpaper.
Empty dust box (8) regularly for optimal dust pick-up
f
performance. Press knob (9) downward and pull it
open, then pour out the dust.
NOTE: Do not use dust box (8) when sanding met-
al. Do not clean the dust box (8) by water.
When sanding is completed, turn off the power
f
switch and remove the sander from the workpiece.
When completely finished using the sander, use a
f
vacuum to dislodge all sand shavings and dust. Wipe
with a clean, soft cloth.
To prevent accidents, turn off the sander and unplug
f
41526
OS 320 PLUS
V|Hz
220-240|50/60
W
320
min
6.000-12.000
-1
mm
230x115
kg
2,3
dB(A)
76
dB(A)
87
dB
(triax vector sum)
h
m/s
4,474
2
m/s
1,5
2
it after use. Clean, then store the sander indoors out
of children's reach.
TRIGGER "ON-OFF" SWITCH
To turn the tool "ON" squeeze the trigger switch (1).
f
To turn the tool "OFF", release the trigger switch (1),
which is spring loaded and will return to the "OFF"
position automatically.
To increase switch life, do not turn switch on and off
f
while tool is under load.
"LOCK-ON" BUTTON
The "Lock-ON" button (2), located near the trigger
f
allows for continuous operation at maximum OPM
without holding the trigger.
TO LOCK TRIGGER "ON": squeeze trigger, depress
ƒ
button and release trigger.
TO UNLOCK THE TRIGGER: squeeze trigger and re-
ƒ
lease it without depressing the "Lock-ON" button.
WARNING: If the "Lock-ON" button is continuously
f
being depressed, the trigger can not be released.
3
PRESELECTING THE ORBITAL STROKE RATE
With the thumbwheel (3) for preselection of the
orbital stroke rate, you can preselect the required
orbital stroke rate, even during operation. The re-
quired stroke rate depends on the material and the
working conditions and can be determined through
practical testing
SANDPAPER INSTALLATION
WARNING: To avoid injury from accidental startups,
f
turn switch OFF and remove the plug from the power
source outlet before making any adjustments.
Before installing sandpaper, make sure the hook
f
and loop fastener base is free of dust and dirt and
that the sander is unplugged.
The hook and loop fastener base will hold any
f
hook and loop sandpaper without clamps or glue.
Simply line up the sandpaper with the hook and
loop fastener base and press together, making
sure front edge of the sandpaper is aligned with
the front edge of the hook and loop fastener base.
There are also provided clamps (5) to fasten non-
f
hook-and-loop sandpaper to the sander. Select
a sandpaper with the correct grit corresponding
to the work to be carried out. To take maximum
advantage of the sander's high removal rate and
smooth finishing. It is essential that the sandpa-
per be properly and tightly secured. Tight paper
also wears less and lasts longer. Insert end of new
1/4 sheet sandpaper approximately 1.5cm under
the paper clamp. Lift up on paper clamp lever and
lock into place. Apply downward pressure to con-
form sandpaper to sanding base. Wrap sandpa-
per around cushion. Lift lever on opposite end of
sander and insert loose end of sandpaper under
the paper clamp. Fit sandpaper against cushion
tightly. Lift up on the lever and lock into place.
To remove used sandpaper, peel one edge away
f
from the hook and loop fastener base until the
whole sheet is free.
CAUTION: Do not use torn or severely worn or
damaged sandpaper. To do so could damage the
surface of the hook and loop fastener base.
OS 320 PLUS
